NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 23
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
10-
46527 Brake Assy, New MC E 1
42543 Brakes Assy, M100 F 1
53162 Brakes Assy, 100, New, MC,162 O 1
44246 Axle Mntg Assy 1
44551 Control Assy, M100, (Also See Eng Linkage) 1
53161 Axle Mntg Assy, M100, Rear, 612 O 1
1
46420 Booster, Brk w/ Master Cyl E 1
F104286 Master Cyl./Power Booster (14894), 0204022687 F 1
NW030198 Master Cylinder Only (0GE52), 2232390 F Ref
NW036134 Bar, Spring Return Bracket, 2770203 F 1
2
46635 Valve, Check, Brk E 1
NW024714 Check Valve (14894), 2226939 F 1
Comm HHCS, 3/8-16 x 1.00 2
F100312 HHCS, 3/8-16 x 1.25 2
Comm Lock Washer, 3/8 4
F9666 Hex Nut, 3/8-16 4
3
NW029869 Brake Line, Cylinder/Valve 1
4
47154 Brake Line, Cylinder/Valve E 1
NW029870 Brake Line, Cylinder/Valve F 1
51267 Brake Line, Cylinder/Valve O 1
5
NW010370EB Stop Light Switch (13445), 8629 1
6
46718 Ftg, Brk, Tee, 03 F 1
NW036464 Tee, Adapter (Edelman), 127030 E 1
7
47155 Brake Line, Switch To Valve E 1
NW029869 Brake Line, Switch To Valve F 1
51266 Brake Line, Switch To Valve O 1
8
NW033848 Washer, Copper, 29/64 E 2
9
NW034758 Brake Fitting, 1/4 x 7/16-20 (79470), M99JT03200 2
10
NW033891 Bleeder Screw 2
11
NW036790 Brake Line, RH Rear/Tee 1
12
NW032343 Tee (79470), 7765 1
NW030263 Adapter, 7/16-24 x 3/8-20 (optional not illustrated) Ref
13
NW030435 Brake Line, LH Rear/Tee 1
14
NW015632 Bracket, Mounting 1
Comm HHCS, 5/16-18 x 0.75 1
Comm Lock Washer, 5/16 1
Comm Hex Nut, 5/16-18 1
15
Comm HHCS, 5/16-18x.75 1
16
F009546 Lock Washer, 5/16 1
17
F009547 Hex Nut, 5/16-18 1
18
41279 Brake Line, Valve/Hose (17.56") 1
19
NW034448 Plug, Equalizer Valve 1
20
NW035241 Equalizer Valve, Warning Only, 1257225 1
NW034447 Equalizer Valve, 1500 (V00541), 25509417 1
F101573 Valve Brake Equalizer,40/60 O 1
21
46599 Line, Brake, Equal-Frt E 1
37673 Brake Line, Valve/Front Tee F 1
22
F101137 Clip, Insulated, .19 ID (KMC), COV041321 2
23
37672 Brake Line, Front Crossover 1
4 ILLUSTRATED PARTS LIST
NOVEMBER 02, 2015
