NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 25
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
10-
46527 Brake Assy, New MC E 1
42543 Brakes Assy, M100 F 1
44246 Axle Mntg Assy 1
44551 Control Assy, M100, (Also See Eng Linkage) 1
53161 Axle Mntg Assy, M100, Rear, 612 O 1
24
F100728 Tee, Run, 3/16 (79470), 7900 1
25
NW022778 Clip, Brake Line (Wagner), FC3052 4
26
1.7347 Hose, Brk, w/o Bracket 1
1.7348 Hose, Brk, w/o Bracket 1
27
F103924 Sleeve, Plastic Coil (96151), 900952-6 30"
28
43114 Plate, Equal izer Valve, Cummins 1
29
Comm HHCS,5/16-18x.75 1
30
Adapter 1
31
NW0305814 Banjo Bolt, M10 x 1.5 x 28 mm 2
32
1.8732 Washer, Copper 10 mmm (1DF85), 24951 4
33
3.2793 Ftg, Brk, 02MP-03FI E 2
34
Brake Line
36
NW036465 Adapter, 3/16 x 1/8 NPT (Edelman), 261320 1
37
NW036466 Ell, 90 Deg. 1/8 NPT (Edelman), 3500X2 1
38
37613 Brake Hose, 18-7/8 ((EIS SP3116),BH 36091 1
F103924 Sleeve, Plastic Coil (Optional for rear axle w/spring) 8”
39
44149 Brkt, Brk Line 1
40
39903 Brkt, Brake Line Support (Cummins) 1
41
152932 Grease Zerk 1
42
F104435 Spring, Extension 1
Comm HHCS, 3/8-16 x 1.25
Comm Hex Nut, 3/8-16
43
NW029715 Connector (Alcoa) 1
Comm Lock Nut, 1/2-13 1
Comm Flat Washer, 5/8 2
44
F016289 Hex Nut, 1/2-20, Jam 1
45
46747 Pedal Wldmnt,Brk,60/100, Zenith 1
37497 Pedal Weldment, Brake 1
NW010254C Bushing, Brass 2
F104444 Bushing, Oilite 1
F014476 Nut, 5/16 Stop, Elastic 1
F016985 HHCS, 3/8-16 x 3.5 GR 5 1
46
NW029876 Shaft Assembly 1
Comm HHCS, 5/16-18 x 1.25 1
Comm Flat Washer, 5/16 1
Comm Lock Washer, 5/16 1
Comm Hex Nut, 5/16-18 1
47
F101146 Clip, Insulated, 1.25 I.D. 2
48
121966 HHCS, 1/4-20x2.5 2
F009704 Washer, 1/4 Flat 4
120380 Washer, 1/4 Lock 2
120375 Nut, 1/4-20 Hex 2
49
400903 Spacer 2
NS
NW029964 Hose, 12, (No Fittings) O 1
NS
3.2792 Ftg, Brk, 07M-04FI O 1
NS
NW032342 Ftg, Hyd, Tee, 03FT-03FT-02FT O 1
