NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 45
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
APRIL 15, 2012
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
17-
44244 Sheet Metal, Chassis Assembly Ref
9
NW035229 Wire Cover 1
F101603 Trim, Rubber, 3.75" (Austin), SD 1250 1
Comm THMS, 1/4-20 x 0.75 2
NW034955 Tinnerman Screw, 1/4-20, U-Type 2
41688 Cover, Wire for Perkins 1004 w/AT545 1
10
40440 Floor Plate 1
Comm HHCS, 3/8-16 x 2.00 2
Comm Flat Washer, 3/8 1
Comm Lock Washer, 3/8 2
F9666 Hex Nut, 3/8-16 2
41785 Plate, Back for Perkins 1004 w/AT545 1
46991 Plate, Deck (Used w/ 46765-9) 1
11
NW027756 Cover, Fuel Sending Unit 1
F100643 SHCS, 5/16-18 x 0.75, Button 1
12
41288 Deck Plate Seal 25.5"
13
40492 Plate, Filler Floor 1
14
NW023065 Screw, Hood Bumper (24617), 3963260 2
NW023066 Bumper, Hood (24617), 3792828 2
F9547 Nut, Hex, 5/16-18 4
Comm Lock Washer, 5/16 4
15
42098 Ba󰀪e, Rubber 1
16
42101 Retainer, Ba󰀪e 1
17
42929 Luggage Rack, Rear Cargo Box, Optional Ref
43315 Luggage Rack, 15H x 28D x 44W Ref
18
44322 Hood Rod Assembly
44526 Hood Rod Assembly, (Deutz) 1
19
38042 Rod Weldment, Hood 1
42074 Rod Weldment, Hood(Deutz) 1
46816 Rod Weldment, Hood(Zenith) 1
20
38043 Bracket, Hood Rod Mnt. 1
21
NW016340 Clip, Hood Lock Rod 1
22
39445 Brkt, Hood Rod Clip, NW 1
38739 Bracket, Hood Rod (Deutz, illustrated) 1
23
Comm Flat Washer, 1/2 1
24
Comm Pin, Cotter, 1/8 x 7/8 1
25
Comm RHMS, 8-32 x 1/2 1
26
Comm Lockwasher, #8 1
27
Comm Nut, Hex, 8-32 1
28
46651 Guard, Fuel Pump 1
29
46647 Brkt, Oil Filter Mounting 1
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per Assy
0
NW034556 Sound Suppression Option REF
47172 Sound Suppression Option
NS
NW034741 Dwg, Instr, Carpet, Floor 1
NS
NW034740 Dwg, Instr, Carpet, RR 1
NS
NW034700 Adhesive, Glue 1
NS
425100 Carpet, Cab Floor, 3/8 21.0 ft
2
NS
425100 Carpet, Cab Floor, 3/8 8.25 ft
2
NS
42393 Insulation, Hood, 47.53 for NW034556 1
NS
42394 Insulation, Hood, 54.26 for NW034556 1
NS
47171 Insulation, Hood, Kit for 47172 1
