NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 47
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
18-
Counterweights Ref
42549 Counterweight, 8,000# DBP Ref
1
NW024329 Cwt, Base Plate, Stl Std
2
37661 Cwt, 6 x 25 x 40, Bottom, Stl 1
3
37662 Cwt, 3 x 28 x 34, Middle, Stl 1
4
37663 Cwt, 2 x 34 x 63, Stl 1
5
37665 Cwt, .75 x 33 x 63, Stl 1
44311 Counterweight, 10,000# DBP, Optional Ref
1
NW024329 Cwt, Base Plate, Stl 1
2
37661 Cwt, 6 x 25 x 40, Bottom, Stl Std
3
37662 Cwt, 3 x 28 x 34, Middle, Stl Std
4
41295 Cwt, 2.5 x 35 x 68, Stl 1
5
41296 Cwt, 3 x 35 x 68, Stl 1
44312 Counterweight, 12,000# DBP, Optional Ref
1
NW024329 Cwt, Base Plate, Stl Std
2
38045 Cwt, 6 x 25 x 40, Bottom, Lead 1
3
38046 Cwt, 3 x 28 x 34, Middle, Lead 1
4
38047 Cwt, 3 x 34 x 63, Lead 1
5
41709 Cwt, 3 x 35 x 68, Lead 1
NS
44712 Bolt Wldmnt, Cwt 3
NS
F100040 Nut, Hex, 3/4-10, Nylock 3
NS
F016241 FW, 3/4 Std, ZC 3
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
18-
41707 Counterweight, 10,000# DBP, Optional REF
4
41295 Cwt, 2.5 x 35 x 68, Stl 1
5
41296 Cwt, 3 x 35 x 68, Stl 1
