NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 49
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E Units
Per
Assy
19-
42579 Fuel System Ref
1
41533
Sending Unit, Fuel Level, w/Gasket 155
F101529
Gasket, Fuel 1
F010824
RHMS, #10-32 x 3/8, Brass
155
F10046
Flat Washer, SAE, .188
155
2
37833
Cap, 1/4 Turn, Vented, Std (49234)
Ref
39037
Cap, Protecto, 1/4 Turn
1
3
NW031890
Block, Spacer (Prior to #97-C-1964)
1
4
NW036198
Adapter, Hose, 5/16 x 1/4 NPT
2
5
F101150
Hose Clamp, #4, .25 - .62
4
6a
F101015
Feed Hose, .31 ID (Perkins &Ford)
A/R
9.2066
Feed Hose, .37 ID Low Press (Cummins)
A/R
6b
F101015
Return Hose, .31 ID A/R
9.1204
Return Hose, .25 ID (Cummins 4BT3.9 Only)
1
7
42542
Fuel Tank, Standard (Inc. 8-12)
1
8
39226
Strap Assembly, Fuel tank
2
9
F101588
Tank Protection Strip
A/R
10
NW036192
Fuel Tank, 21.1 Gallon, w/Cap
1
11
NW022788
Harness, Fuel Tank
Ref
12
F102221
SHCS, 3/8-16 x 2 1/2
2
14
41433
Cap, Protect-O-Seal, 1257 w/6.75 Scr
1
15
NW036194
Tank, Fuel, 20 Gal (For Safe Cap)
1
16
44319
Protect-O-Seal, Gas Cap and Tank, Option
Ref
17
37433
Clip, Insul, 1.25 ID, .53 Hole (KMC), COV-2117Z1
1
18
F100196
HHCS, 3/8-24 x 1-1/4, GR5
2
Comm
Nut, 3/8-24
2
19
F009665
Lock Washer, 3/8
1
20
F009669
Washer, 3/8
2
21
Comm
HHCS, 5/16-18 x 2.5
2
22
Comm
Nut, 5/16-18 Hex
2
23
NW031786
Ell, Steel, 90°
2
24
F009666
Nut, 3/8-16 Hex
2
25
39582
Nut (K5436), 33532129
2
26
39581
Packing (K5436), 566004
2
27
39583
Plug (K5436), 650204
2
28
NW036196
Tube, Fuel Return, 9.50", (Diesel)
1
29
39584
Washer(K5436), 9200154
2
30
39580
Water Separator (K5436), 2656086
1
31
42051
Ftg, Hyd, 06H-04MP (For .37 ID Hose)
1
NW036198
Fitting, Hose, 5/16 Hose x 1/4 NPT
1
32
43118
Ftg, Hyd, 14mm-04FP (Cummins)
2
3.3077
Ftg, Hyd, 04H-04MP (Perkins, 1004-42)
1
33
40709
Kit, Glass Bowl (Includes items 34-37)
1
34
39585
Washer (K5436), 26560016
1
35
39586
Gasket (K5436), 490786
1
36
39587
Container, Glass (K5436), 26560075
1
37
39588
Seal (K5436), 26560014
1
38
NW027618
Line, Fuel, 5/16 x 15
1
39
NW031786
Line, Fuel, Water Separator
2
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
