NMC-WOLLARD 100 - Page 291

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 53
CHAPTER 4 REPAIR PARTS
JANUARY 31, 2007
4 ILLUSTRATED PARTS LIST
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
20-
42954 Steering Assy, w/AT545 Trans Ref
Hydraulic Assembly, AT545 Trans Ref
1
1.7138 Column, Steering, Hyd. (V00534), 204-1043 1
152283 Tie, Cable 11.88”, 50# 2
2
1008873 Fitting, Hyd., Crimp, Ell, Swivel 1
F104402 Fitting, Hyd., Ell, 06H-06FJX90 1
3
NW036560 Fitting, Hyd.,Adapter, Ell, Adj. 1
4
3.2519 Fitting, Hyd., Connector, ST 3
5
F100979 Clamp, Hose #6, .44 - .78 8
6
3.1564 Fitting, Hyd., Adapter, Ell 2
7
1011081 Cyl Steering, 1" Shaft, 7.4 Stroke (0ZK80), 2513 1
1012065 Seal Kit, Steering Cylinder 1
8
NW034968 End, Tie Rod, 3/4-16, RH 40-60 (0AT39), 06-60360 2
9
8796.60 Hose Assy., #6C 87.4¨ 2
8796.5 Hose Assy, #6M, 74.43” 2
10
41704 Hose Assy., Power Steering #6M, 31¨, ST/EL 1
11
42042 Orbitrol, Steering (96151), 211-1007 1
12
NW036491 Wheel, Steer, Eaton, Column 1
13
150526 Nut, Steering, Hyd. 1
14
202736 Button, Horn Kit 1
15
NW026799 Fitting, Hyd. Adapter, Ell, Pressure (01276),
FF5300-0645
1
16
3.1572 Fitting, Hyd. Adapter 2
17
F002691 Tee, 3/8 Mall 1
18
93174 Fitting, Pipe 90D, 3/8-18 NPT M/F 2
19
NW029020 Valve, Relief, Inline (V00534), 9231100PSI 1
20
1008789 Fitting, Hydraulic, Adapter, ST 1
21
38387 Hose Assy., #6M, 56.0¨, ST/EL 1
22
1.8808 Fitting, Hyd., Adapter, Hose Barb, Swivel 1
23
9.2066 Hose, .37 ID x .66 OD 100¨
24
38966 Reservoir, Hyd., 1 Gallon 1
25
NW035531 Cap, Hyd. Tank 1
25a
43449 Dipstick (included w/25) 1
26
41312 Brkt. Hyd. Tank, 1/8 x 4 x 8 5/16 1
27
F100821 Fitting, Pipe, R Bushing, 3/8 x 1/4 1
28
NW034729 Fitting, Hyd., Adapter, Tee, Branch 1
29
NW034736 Fitting, Hyd., Adapter Ell 1
30
41666 Brkt. Hyd. Tank (100D6A) 1
30a
41313 Brkt, Hyd Tank (100D4A) & AT545 1
31
SWXHF277 Fitting, Hyd., Adapter 1
32
41352 Hose Assy. #12L, 15.0¨ ST/ST 1
33
91940 Fitting, Hyd., Connector, ST 1
34
1008811 Fitting, Hyd. Connector 1
