M100 Tow Tractor Manual No. 46052
PAGE 57
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
21-
44241 Steering Assembly, C6 Transmission Ref
1
NW034686 02023-0423 Horn Button Kit (V00548) 1
2
NW023027 Hex Nut 1
3
NW023028 Flat Washer 1
4
NW034684 79-219 Steering Wheel (79995) 1
5
NW026372 Wire Assy, 16 GA, Blk, 75-5 17
6
49008 07809658 Steering Column 10” (52793) 1
7
NW035441 Bracket, U-Bolt 1
F100075 Lock Washer, Int. Shakeproof 2
8
NW030946 Steering Column Boot 1
9
NW023913 Coupling Assembly 1
NW023914 Pinch Bolt 1
10
NW023510 Steering Gear Assembly 1
NW034403 Lock Washer, SAE Hardened, 7/16 3
11
F002547 Cotter Pin, 1/8 x 2.00 2
12
NW023017 Hex Nut, 7/8 UNF, Jam 1
13
NW023033 Lock Washer, 7/8 1
14
NW036173 Pitman Arm 1
3.3301 HHCS, 1/2-13 x 3.00 2
F0016825 Hex Nut, 1/2-13 2
15
NW029931 25598 Drag Link (incl. items 15-18 and 21-22)
(Mason Forge & Die)
1
16
NW014983 5896 Spring, Seat 2
17
NW014982 10544 Ball Seat 2
18
NW023052 10543 Plug - Drag Link 1
19
F009217 Grease Zerk, 1/8, 90 Deg. 2
20
NW014984 5339D Plug, Washer Spring Disc 1
21
NW023051 3899D Plug -Ball Seat 1
22
NW014981 836D Drag Link Plug, Flat 1
23
44076 S-1827D Drag Link Cap 2
24
40997 7/16 x 1.75 HHCS, GR8 1
25
40998 7/16 x 2.25 HHCS, GR8 2
26
F018486 7/16 SAE Hardened FW 3
27
152283 T501 Tie Cable, 11.88” (7J925) 2
28
F100843 38020 Connector, 2-Way (Whitaker) 1
29
NW023916 Bearing Assembly 1
30
NW022990 Spring 1
31
NW023916 Bearing 1
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2007
