NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 59
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
22-
Hydraulic Power System - C6 Ref
1
F102526 Power Steering Pump (52793), 07840052 Ref
41755 Reservoir, Power Steering (V00548), 7811292 1
2
F100979 Hose Clamp, #6, 3/8-7/8 2
3
NW033586 Relief Valve (V00548)(Cummins), 07809229 Ref
4
NW034570 Hose, Tee to Pump, 3/8 ID x 32" 1
F101679 Hose, Tee to Pump (Cummins) 1
5
F104418 Tee, Union (Thompkins), 29T6 1
6
NW029964 Hose, Tee to Steering Gear, 12" 1
7
NW026800 Elbow (01276), FF5300-0646 1
8
NW029966 Hose, Steering. Gear to Booster, 30.5" 1
38828 Hose Asm, PS, #6M 30.5 El/El, Perkins T3 Turbo 1
9
NW026799 Elbow (01276), FF5300-0645 3
10
NW027592 Steering Gear (see gure 21) 1
11
38387 Hose Assembly, Pump to Booster, #6M, 56", Str./90
(used with Perkins engine)
1
NW029965 Hose Assembly Pump to Booster (Cummins) 1
48318 Hose Asm, PS, #5M 49” St/St Perkins T3 Turbo 1
12
NW029878 Hose, Tee - Booster, 3/8 ID x 21" 1
13
F104286 Master Cylinder/Power Booster (14894), 2771072 Ref
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2009
