NMC-WOLLARD 100 - Page 331

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 93
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
38-
44719
Instrument Panel Assembly
Ref
1
NW036129
Voltmeter (16476), 06863-38
1
2
NW024700
Gauge, Engine Coolant Temp. (8S377) ,06348-10
1
3
NW024699
Gauge, Engine Oil Pressure (8S377), 06103-12
1
4
NW024701
Gauge, Trans Oil Temp. (16476), 06118-12
1
5
NW024702
Gauge, Fuel (8S377), 06101-19
1
41605
Gauge, Fuel w/ Indicator Light, Optional (V00542),
103108
1
6
NW031860
Switch, Ignition (Perkins) (V00517), 2846129 M
1
F104281
Switch, Keyless, Ignition, Anti-Restart (Ford, Cummins)
1
NW030247
Disc, Ignition (Ford) (Adhesive)
1
52487 Placard, Ign Switch, Al, Adhesive 1
43958
Keyless Anti Restart Ignition, Perkins N
Ref
2.0134
Breaker, Circuit, 20A
1
44735
Harness, Preheat, 1004
1
44720
Keyed Anti Restart Ignition, Perkins N
37844
Switch, Ignition, Keyed (Option Ford/Cummins) (77326),
31-302
Ref
37844-1
Key For 37844 Ignition Switch
1
2.0134
Breaker, Circuit, 20A
1
44735
Harness, Preheat, 1004
1
6A
NW035374 Switch, On/O󰀨 w/ Load (Included in 44720)
1
NW035385 Insert Switch, Plug
1
7
41434
Gauge, (16476), 100222
1
8
(See Figure 38, 2of3)
Ref
9
(See Figure 38, 2of3)
Ref
10
NW034176
Work Light Switch, Rocker (Simms), 511005
1
NW035383 Work Light Insert (56289), 59L.430
1
11
NW035376
Head/Tail Light Switch (56289), 511106
1
NW035386
Head/Tail Light Insert (56289), 596648
1
12
(See Figure 39)
Ref
13
43566
Tachometer, F300, Option
1
14
37443
Speedometer, 0-20mph, Option
1
NW033159
Sender, Generator
1
37445
Adapter, Speedometer 1
37446
Gear, Speedometer Driver
1
37447
Adapter Speedometer
1
NW021261
Plug, Button
1
NW033179
Harness, Electric
1
NW033180
Wire, Speedometer Ground
1
NS
37654
Bulb, Repl. for Switches (65439), LBSPR-0100
Ref
NS
NW036767
Bulb, Replacement For Dash (V00506), 596956
Ref
NS
44238
Harness Dash Guage, Lights, Switches
1
NOTE: 43967 Includes Standard Coolant Temperature & Oil Pressure Gauges
4 ILLUSTRATED PARTS LIST
AUGUST 15, 2014
