NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 99
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
38-
Instrument Panel P Ref
1
48148 Potentiometer 1
49262 Knob 1
2
NW024701 Gauge, Trans. Oil Temp. 1
3
NW035376 Switch, Light 1
NW035386 Insert, Green 1
4
NW034176 Switch, Light 1
NW035383 Insert, Green 1
5
41434 Gauge, Hourmeter 1
6
52656 Gauge, Fuel,Temp,Oil, Volts 1
7
NW035385 Insert, Glow Plug 1
8
45143 Insert, Engine Stop, Red 1
9
37247 Insert, Park Brake On 1
10
53067 Speedometer, GPS 1
11
NW035388 Insert, Switch Brake 1
12
52370 Tachometer 1
13
51826 Switch, Ignition 1
52487 Placard, Ign Switch 1
14
15
NW035394 Switch, Rocker (tractor with cab) 1
NW035395 Insert,Switch Blower (tractor with cab) 1
16
17
52710 Light, Pilot, LED, Green (tractor with cab) 1
18
52735 Switch Assembly (tractor with cab) 1
19
NW035378 Housing (for items7,8,9,11) 1
NS
44238 Harness, Dash 1
38-
52725
Grp, TT Inst Panel, CDF P
Ref
19
NW035378
Housing Light Indicator
1
20
NW036731
Holder Switch, End
4
21
NW035379
Blank Switch Cover
2
NS
52687
Panel, Sheet, Inst
1
NS
NW036732
Holder Switch Middle
2
38-
52638
Grp, TT Shutdown, Oil/Temp, W/Ind P
Ref
2
NW035378
Housing Light Indicator
1
8
45143 Insert, Engine Stop, Red 1
NS
NW035382
Inser Switch Blank (See Fig 64)
1
NS
52721
Switch, Pressure, 15#
1
NS
NW031392
Switch, Temp, 220F
1
NS
49415
Relay Time Delay
1
NS
48152
Holder Fuse Inline
2
NS
48154
Diode, 1A, ATM Mini
2
38-
53003 Gauge Pkg, Std, 140 P Ref
2
NW024701 Gauge, Trans. Oil Temp. 1
5
41434 Gauge, Hourmeter 1
6
52656 Gauge, 4” Fuel, Temp, Oil, Volts 1
NS
52997 Harness Dash 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
