NMC-WOLLARD 100 - Page 351

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 113
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
JUNE 23, 2014
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
42-
Harnesses Ref
8
42280 Diode Assembly, Modies (Cummins) 1
9
NW031776 Harness, Starter (Cummins) 1
NS
44236 Harness, Rear, C6 (22 Pin) 1
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
42-
Harnesses Ref
10
50151 Harness, ECM/Thrt/Ind.L, QSB3.3 1
10A
50108 Conn, Deutsch, DRC26-60S-04 1
10B
45010 Pin, Deutsch 9
10C
45011 Seal, Cavity 51
10D
F100516 Wire, 12Ga, BK 72"
10E
308070 Socket, Deutsch,12-14 Awg 4
10F
46264 Conn, EL, Deutsch, Wedge, WP-4S 1
10G
46261 Conn, Deutsch,P DTP06-4S 1
10H
2.1514 Wire, 12 Ga, Black 40"
10J
2.0797 Term, Ring 3/8, 10-12 1
10L
F100848 Term, Ring #10, 18-22 2
10M
306657 Wire, 20 Ga Black 136"
10N
Term, Push-On, 1/4, 10-12, UNINS 1
10Q
Term, Push-On, 1/4, 18-20, UNINS 1
10R
308058 Wire, 12Ga, Red 39"
10S
37305 Conn, Shroud, Waytek #38044 1
10T
48592 Pin, Waytek, 18-20 Ga, #31034 3
10U
37309 Seal,16-18 Ga, Waytek # 39000 3
10W
45357 Conn, Throttle Sensor REF
10X
50435 Wire 18/3 Twisted Shielded 52"
