M100 Tow Tractor Manual No. 46052
PAGE 115
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
42-
Harnesses Ref
11
44237 Harness Assy, Dash 1
11A
306251 Conn, 22 Pin, Blkhd, Int 1
306253 Conn, Lock, 22 Pin, Scnd 2
37309 Seal, Wire, Gray, 18-16GA, Pack 20
43893 Seal, Cable, 12Ga GPT, Pack, Waytek, #39002 1
11B
F101548 Conn, Male, 1 WAY, Waytek, #38000 1
11C
F101549 Conn, Fem, 1 WAY, Waytek, #38001 1
11D
F101551 Conn, 2 Pos, Male, Waytek, #38003 1
11E
F101550 Conn, 2 Pos, Fem Half, Waytek, #38002 2
11F
37409 Conn, Light 1
11G
37408 Conn, Switch 3
11H
203151 Conn, Butt, 12-10, Waytek, #32965 1
12
44238 Harness, Lights, Gauge & Switch 1
12A
F101549 Conn, Waytek, #38001 1
12B
F101597 Light Bulb 4
12C
NW033538 Light Assy 2
12D
37409 Conn, Light 4
NS
46872 Harness,Dash,Indicator Lights 1
37409 Conn,Light (65439), SPR 913 328 6
37049 Term,1/4 Fem Bld,14-18 Ga (00779), 42238-2 6
203164 Term,Ring,#8,#16-14 Awg, 31902 1
F101647 Wire, 16 Ga Pnk GXL, GXL16-P 2500 29
NS
46873 Harness,Dash,Gauge/Light 1
F101597 Light,Gauge,Non-Shutdown (16476), 06215-00 3
F102204 Term,Push-On,1/4,F,16-14GA (58961), 31513 1
F100851 Term,Butt,14-16 Ga,Vinyl 1
F002958 Wire,16 Ga Blk GXL16-0 2500 18
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
