NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 117
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
43-
42034 Cab Assembly, Option, w/o Roof Vents Ref
44224 Cab Assembly, Option, w/ Roof Vents
44225 Cab w/ Rear Slider (No Heat/Defrost)
44223 Cab, Std (No Heat/Defrost)
46059 Cab, 11", M100 w/ 39" Clear, Opt
51370 Cab, 11”, W/Vents O
1
42179 Windshield Glass, Front 1
2
37711 Seal, Windshield Glass A/R
3
46092 Trim and Seal, Front 110”
4
45878 Door Assembly, R.H. (Prior To 07-C-3052 Order 46311
w/ This Assy.)
1
45878K Door Assembly, R.H. Complete (incl wldmt, glass,
latch, foam, etc)
1
1.7524 Pin, Clevis, .25x..88 2
50122 Ring, Rue, Hvy, 1/4 Dia 2
45739 Door Wldmnt, RH A 1
45995 Mounting Bracket, Door Latch 2
45756 Door, Latch Cover, LH 1
45098 Striker Plate, Door 1
44961 Trim, W/ Seal, .13 x .75 A 160"
46092 Trim, w/ Seal, .12-.19 x 1 A 20.62"
NS
45795 Latch Assembly, Door, R.H. 1
45783 Paddle Handle, RH A 1
46040 Clevis, Yoke, Mod A 2
406206 Cut, 4062, 1" A 1
6
46311 Hinge Wldmnt, RH Door 2
7
45882 Window Assembly, Door, R.H. (Inc Glass Items 60-62) 1
45882-11 Vertical Rail Seal Kit (2 purchase), 64-0390-101 1
45882-12 Latch Keeper Assy (TPE-213), 64-0380-103 1
45882-13 Latch Keeper Assy (TPE-233), 64-0380-104 1
10
45879 Door Assembly, L.H. (Prior To SN 07-C-3052 Order
46311 w/This Assy.)
1
45879K Door Assembly, L.H. Complete (incl wldmt, glass,
latch, foam, etc)
1
1.7524 Pin, Clevis, .25x..88 2
50122 Ring, Rue, Hvy, 1/4 Dia 2
45738 Door Wldmnt, LH A 1
45995 Mounting Bracket, Door Latch 2
45756 Door, Latch Cover, LH 1
45098 Striker Plate, Door 1
44961 Trim, W/ Seal, .13 x .75 A 160"
46092 Trim, w/ Seal, .12-.19 x 1 A 20.62"
11
45877 Door Latch, L.H. 1
45784 Paddle Handle, LH A 1
46040 Clevis, Yoke, Mod A 2
406206 Cut, 4062, 1" A 1
12
46312 Hinge Wldmnt, LH Door 2
46310 Washer, Hinge, Brass 2
4 ILLUSTRATED PARTS LIST
NOVEMBER 02, 2015
