M100 Tow Tractor Manual No. 46052
PAGE 137
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
52-
43742 Hitch - 3 Level Ref
1
37763 Plate Weldment, Hitch Linkage 1
2
43818 Mount, Hitch Linkage, 3 Level 2
3
43817 Hitch Weldment, 3 Level 1
4
43816 Pin Weldment, 3 Level Hitch 1
5
90562 Clevis, 3/8-24 x 3/8 Pin w/Pin 2
6
416501 Cut, 4165, 2.00 (Rod 3/8-24) 1
7
428703 HHCS, 5/8-11 x 2-3/4, GR5 4
8
F016828 5/8 Flat Washer 4
9
F016829 5/8 Lock Washer 4
10
F100002 5/8-11 Hex Nut 4
11
F101448 HHCS, 3/8-16 x 1-1/2, GR5 8
12
F009665 3/8 Lock Washer 4
13
F009666 3/8-16 Hex Nut 4
14
9413534 3/8-16 Nylon Hex Nut 4
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
52-
37757 Hitch - 2 Level Ref
1
37763 Handle, Linkage 1
2
37765 Bracket 2
3
37758 Weldment 1
4
37759 Pin 1
5
90562 Clevis 2
6
37764 Rod, Threaded 1
7
428703 HHCS, 5/8-11 x 2-3/4, GR5 4
8
F016828 5/8 Flat Washer 4
9
F016829 5/8 Lock Washer 4
10
F100002 5/8-11 Hex Nut 4
11
F101448 HHCS, 3/8-16 x 1-1/2, GR5 8
12
F009665 3/8 Lock Washer 4
13
F009666 3/8-16 Hex Nut 4
14
9413534 3/8-16 Nylon Hex Nut 4
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
52-
45588 Hitch, E-Type w/ Remote Ref
1
45586 Brkt, Hitch Remote 1
2
37765 Bracket 2
3
37758 Weldment 1
4
37759 Pin 1
5
90562 Clevis 2
6
37764 Rod, Threaded 1
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2007
