NMC-WOLLARD 100 - Page 439

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 201
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
81-
45503 Linkage Sys, Cummins 4B4.5NA/C6 Q Ref
44326 Shifter, C6, 4B, Quad (Inc Items 16-23)
1
37646 Bar, Ext, Park Brk Cable 1
3
39924 Spring, Modulator Return 1
4
NW032273 Park Brake Cable 1
Comm HHCS, 5/16-18 x 1.25 1
F014476 Stop Nut, 5/16-18 1
5
F101863 Ball Joint, 1/4-28 2
6
39925 Bracket, Return Spring 1
7
39904 Bracket, Weldment, Modulator 1
8
NW034690 Bracket, Actuator, Modulator 1
9
45505 Rod, Throttle, M100 1
10
41706 Bracket, Return Spring 1
11
NW021911 Spring, Carb return 1
12
NW034717 Cable, Modulator, Felsted, 60DPC (V00546), FC2179 1
13
NW034718 Kit, Slip Link, Felsted, 60DPC6 1
14
NW034731 Clip, Cable Mounting 1
15
NW034733 Shim 1
23
38422 Park Brake Plate, lever 1
28
F100306 HHCS 5/16-18 x 0.75 4
29
F009546 Lock Washer, 5/16 4
30
F009547 Hex Nut, 5/16-18 4
31
40435 Accelerator Linkage 1
Comm HHCS, 1/4-20 x 0.75 4
Comm Lock washer, 1/4 4
Comm Hex Nut, 1/4-20 4
32
F001005 Cotter Pin 2
33
NW014718 Bearing 1
F009549 Flat Washer, 5/16 2
34
37616 Accelerator Pedal 1
Comm HHCS, 1/4-20 x 3.50 1
Comm Lock Nut, 1/4-20 1
Comm Flat Washer, 1/4 2
35
NW022971 Accelerator Pedal Bracket 1
Comm HHCS, 1/4-20 x 1.00 2
Comm Flat Waher, 1/4 2
Comm Lock Washer, 1/4 2
Comm Hex Nut, 1/4-20 2
36
F016985 HHCS, 3/8-16 x 3.50 1
Comm Hex Nut, 3/8-16 1
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
