NMC-WOLLARD 100 - Page 447

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 209
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
Also See Figure 79 & 41
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
85-
45500-3 Elec Assy,M100,4BT4.5QSB/C6
3.1820 Ftg,Hyd,Tee,02MP-02FP-02FP (V00565) 1
3.3329 Nut,Hex,M6 X 1.0,ZC *NS* 1
42280 Diode Assy,Modif 1
37733 Clip,Insul,.62 ID, .53 Hole COV 1117 2
44280 Harness,Eng,Cummins,100 (See Figure 46) 1
F100780 Ftg,Hyd,08MP-02FP 1
F101115 Clip,Insul,.44 ID, .41 Hole COV 0813 3
F101526 Sender,Temp,Hi-Range,1/8 NPT (8S377) 02022-00 1
F101527 Sender,Oil Press,0-100#,1/8NPT (V00542) 02505-00 1
F101680 Clip,Insul,1.75 ID, .41 Hole COV2913ZI 1
F102160 Relay,Starter,12V (V00549) F498 1
F103925 Nut,Hex,M10X1.5P,GR8.8,ZC MNC5 1
F016765 RHMS,#10-32 X 3/4,ZC 1
NW010518FB Strap,Ground,4 GA X 9" (59587) 1
NW02149 Switch,Oil Pressure,Hourmeter (13445) 1
NW030236 Sender,Temp,Hi-Range,1/4 NPT (8S377) 02023-00 1
NW031487 Nut,Hex,M5 X 0.8,ZC 1
3.3197 HHCS,M10 X 1.50 X 30MM,GR8.8 2
NW031776 Harness,Starter (See Figure 46) 1
44236 Harness,Rear,C6,22 Pin Conn (See Figure 42) 1
41528 Ftg,Hyd,M10MB-02FP 9235-10-02 1
41529 Washer,O Ring,M10 For 41528 9500-10MM 1
42980 Harness,Ground Wire,200MB4 (See Figure 46) 1
NW034410 Cable,Battery,58",1 GA,BLK 1
2.3265 Cable, Welding, Neopren 63”
2.3359 Terminal, Battery, Neg 1
2.3262 Terminal, Ring, 3/8 1
RF090896 Sleeve, Alum Fbrgls 40”
46036 Cable Assy, Grnd 1
