NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 225
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
92-
46800-6 Cooling Sys,M100,QSB4.5/C6 1
1
46412 Radiator/Oil/Cac ASssy,QSB4.5, 12932CP 1
1A
Cap Radiator 1
2
46447 Support Wldmnt,Rad,100/140,28"W 1
4
46463 Strap,Radiator Mnt,Top 1
6
46551 Tube,Rad,W/I,100/140,QSB4.5,T3 1
7
45036 Hose,Rad,Lower,200MB4V2, 20172S 2
8
37551 Hose,Rad,1.75 X 12.25, 20057S 1
9
44544 Reservoir,Coolant Overow, BVR-4 1
9A
40164 Cap Reservoir 1
10
44556 Brkt,Coolant Reservoir 1
11
F100938 Clamp Hose,#48,2.56-3.50 1
11
F101140 Clamp Hose,#32,1.56-2.50, 5732 2
11
F011057 Clamp Hose,#36,1.81-2.75 3
12
203566 Isolator,Rubber,Bushing,Center, 60230 2
13
RF090504 Tbg Vinyl 0.43 X 0.06W 62
14
F100669 Valve Drain,1/4" NPT,BRS 1
15
49446 Strap Radiator Mnt 1
16
F104402 Ftg, Hyd,06H-06FJX90 3
17
NW 034729 Ftg, Hyd,TEE,04MP-04FP 1
18
NW 034736 Ftg, Hyd,06H-04MP90
19
3.1571 Ftg, Hyd,06MJ-04MP 1
20
9.2066 Hose 0.37 ID Low Press In 96"
21
43459 Angle,Mnt,Radiator 22
NS
NW 036097 Clip Retain,Res Hose 1
NS
F101295 Ftg, Hyd,08MJ-10MB90 2
NS
Ftg, Hyd,08MJ-12MP,848-FS-08X12 2
NS
Ftg, Hyd, Mod 1
4 ILLUSTRATED PARTS LIST
APRIL 15, 2012
