NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 243
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
101-
46325-2 Linkage Sys,M100,QSBT4.5/AT
1
37646 Bar,Ext,Park Brk Cable 1
3
39924 Spring,Modulator Return 1
4
NW031807 Cable Assy,Prk Brk,11.75" (92867), 16567901 1
5
F101863 Ball Joint,ND,1/4-28,1/4-28ST (0NZJ1), R107G 2
8
NW034690 Bar,Actuator,Modulator,DPC6 1
31
40435 Accelerator Linkage 1
COMM HHCS, 1/4-20 X 0.75 4
COMM LW, 1/4 4
COMM Hex Nut, 1/4-20 4
32
F001005 Cotter Pin 2
33
NW014718 Bearing 1
F009549 FW, 5/16 2
34
37616 Accelerator Pedal 1
COMM HHCS, 1/4-20 X 3.50 1
COMM Lock Nut, 1/4-20 1
COMM FW, 1/4 2
35
NW022971 Accelerator Pedal Brkt 1
COMM HHCS, 1/4-20 X 1.00 2
COMM FW, 1/4 2
COMM Lock Washer, 1/4 2
COMM Hex Nut, 1/4-20 2
36
COMM HHCS, 3/8-16 X 3.50 12
COMM Hex Nut, 3/8-16 12
37
NW022767 Lever, Park Brake 1
42460 Rubber Hose For Park Brake, Optional 1
39
406205 Cut,4062, 2.25" 1
40
45357 Sensor,Throttle Position,Cummins, TPS001 1
41
308224 Brkt,Accelerator 1
42
46001 Brkt,Mod Cable Mnt,100DCTA 1
NS
NW021911 Spring,Carb Return (V00553) 1
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
