NMC-WOLLARD 100 - Page 491

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 253
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
106-
46482 Pump Assy, Gear,4B4.5T3 1
47325-9 Steering Assy, M100 Hydraulic 1
1
46420 Master Cylinder W/Booster 1
3
NW036560 Ftg, Hyd, 08MB-06MJ90 1
4
3.2519 Ftg, Hyd, 06MJ-08MB 3
5
F100979 Clamp, Hose,#6,.44-.78 (79470),5406 AR
7
1011081 Cylinder Steering 2B 7.4 ST 1
8
44738 Gauge,Sight Plug,3/4 NPT (Lube Devices),LSP151-05-01 1
9
8796.50 Hose Assy, #6M 74.43", ST/90 2
10
41704 Hose Assy, PS, #6M, 31", ST/ST 1
11
1.7864 Steer Unit, 5.9 CI 1
15
NW026799 Ftg, Hyd,Ell,Press (01276), FF5300-0645 1
16
3.1572 Ftg, Hyd,06MJ-06MP (V00565) 2
17
F104418 Ftg, Hyd, Tee, Union 1
18
3.1564 Ftg, Hyd, 06MJ-06MP90 2
19
NW029020 Valve,Relief,Inline Adj,1100PS (V00534) 1
20
1008789 Ftg, Hyd, 08MJ-06MP 1
21
8797.107 Hose Assy, #8, 35”, ST/90 1
23
9.2066 Hose 0.37 ID Low Press AR
24
38966 Reservoir Hyd, 1.75 GAL 1
25
202993 Breather,3/4 NPT,STL 1
26
46225 Brkt, hyd Tank 1
28
3.1391 Ftg, Hyd,Tee,06MP-06FP-06FP (V00565), 5602-06-06-06 1
29
46247 Ftg, Hyd,06H-06MP90 (V00565), 6/6/4501 1
30
46234 Angle, Hyd Tank
31
NW034365 Ftg, Hyd,08MJ-12MP 1
32
46240.6 Hose Assy,#12L, 34",ST/ST 1
33
46094 Ftg, Hyd,12MJ-16MB (V00565) 1
34
91926 Ftg, Hyd,08MJ-10MB90 (V00565), 6801-08-10-NOW 1
35
F002691 Ftg,P,Tee,06 Mall 1
36
46642 Pump Hyd, Gear,.66CID,SAE"A"11T 1
43834 Gasket,Hyd Pump,SAE A-2BOLT (15605), 102930-000 1
37
202735 Steering Wheel, 14" Eaton 1
38
202736 Button Hord For VIP Wheel 1
39
150526 Nut Hex, 13/16-20 1
41
49008 Column Steering, 10" W/Wire Flag I 1
NW035372 Column Steering, 10" W/Wire Spring J 1
42
F103213 Clamp, 1.75 ID Mu󰀪er 1
43
45592 Cover Wldmnt, Steer Dash 1
44
NW034968 Tie Rod End 3/4-16 RH 2
NS
44739 Ftg, P, 12MP-12FP45, BIP 1
NS
46246 Ftg, Hyd, 06H-06MP 1
NS
152495 Nut Hex, 3/4-16, JAM 2
NS
306346 Nutsert, 1/4-20, .165-.260, Open 3
4 ILLUSTRATED PARTS LIST
APRIL 15, 2012
