NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 255
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
107-
48390 Grp,M100,ENG,B3.3TAA/C6 T3 1
1
48390-1 Eng/Trans/Mntg Assy,B3.3TAA/C6 T3 1
2
48390-2 Linkage Sys,B3.3TAA/C6 T3 1
3
48390-3 Elect Assy,B3.3TAA/C6 T3 1
4
48385-4 Exhaust Sys,B3.3TAA/C6 T3 (QSB) 1
5
48385-5 Air Intake Sys,B3.3TAA/C6 T3 (QSB) 1
6
48385-6 Cooling Sys,B3.3TAA/C6 T3 (QSB) 1
7
42561 Fuel Sys,B3.3TAA/C6 T3 1
8
48390-9 Hyd Assy,B3.3TAA/C6 T3 1
9
43093 Battery Sys W/Box 1
10
47307 Pump Assy gear,B3.3,T3 1
11
46989 Panel Assy Side M100 1
12
47239 Drive Shaft B3.3TAA/C6 T3 1
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
NS
309134 Filter, Lubricity Option, B3.3TAA/C6,T3 1
1
309135 Filter Assy,Fuel,Lubr 1
2
47278 Washer Seal, Cummins 1
3
309150 Conn,Banjo,Fuel 2
4
309151 Bolt,Banjo,Fuel,Cummins 2
4 ILLUSTRATED PARTS LIST
APRIL 15, 2012
