M100 Tow Tractor Manual No. 46052
PAGE 257
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
108-
48390-1 Eng/Trans/Mnt Assy,B3.3TAA/C6 T3 1
48385-1 Emg/Trans/Mnt Assy,QSB3.3/C6 T3 1
53425-1 Eng/Trans/Mnt Assy, QSB3.3/GM P 1
53535-1 Eng/Trans/Mnt Assy,B3.3TAA/C6 T3 P 1
1
47240 Engine, Cummins B3.3 Turbo T3 1
46950 Engine, Cummins QSB3.3 T3
2
3.1820 Ftg, Hyd, Tee, 02MP-02FP-02FP (V00565) 1
3
NW030236 Sender, Wa ter Temp, 1/4NPT 1
4
NW021649 Switch, Oil Pres sure Hr Me ter 1
5
F101527 Sender, Oil Press, 1/8NPT 1
6
206405 Fan 1
7
208609 Fan Spacer, Modied 1
8
206498 Belt, Serpentine 60A 1
9
206500 Alternator 1
10
206407 Oil Filter 1
11
206408 Fuel Filter Element 1
12
206409 Starter 1
13
38733 Ftg, 02MP-02FP 1
14
207649 Kit, Water Pump, Cummins 1
15
205065-6 Oil Fill Cap (OB30000) 1
16
205065-4 Pan, Oil (OP30002) 1
17
205065-7 Manifold, Exhaust (XM30001) 1
18
205065-8 Manifold, Exhaust Gasket (C613012558) 1
19
205065-3 Dip stick, Oil Level (LG30001) 1
20
NW 034441 Trans,C6,3 SPD,2.40SR,W/BRAKE (39569) 1.0
21
F100444 Pin, Dowel 1/2 x 1 ZP 2
22
Drive Flange (0AT39) 3907620 1
23
1.8125 Flex Plate (0AT39) D5TZ-6375A 1
24
1.9016 Ring, Reinforcing (0AT39) C20Z-6A366A 1
25
Flex Plate (0AT39) 3907619 1
26
HHCS, Self Locking, 7/16-20x1-1/4 (0AT39) 8
27
SHCS, 3/8x1-1/4 4
28
1.8498 Nut, Washer Lock 3/8-24 (03718) 4
29
NW034441 Adapter, C6 Transmission 911580 1
30
43365 Converter Assembly, HD EATP-7902-BB PR 1
31
44940 Angle,Dipstick Mnt,C6 1.0
32
F100340 HHCS, 7/16-14x2.25 6
F18486 Washer 7/16 Lock 6
33
Comm HHCS 1/4-20x2.75 2
F9704 Washer, 1/4 Flat (both sides) 4
F13588 Nut 1/4-20 Nylok 2
34
F100320 HHCS, 3/8-16x2.75 1
F9665 Washer 3/8 Lock 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
