NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 263
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
110-
48390-2 Linkage Sys, M100 B3.3TAA/C6 T3 Ref
48385-2 Linkage Sys, M100 QSB3.3T/C6 T3 Ref
53425-2 Linkage Sys, M100, QSB3.3/GM P Ref
53535-2 Linkage Sys, M100 B3.3TAA/C6 T3 P Ref
1
37646 Bar,Ext,Park Brk Cabl 1
3
39924 Spring,Modulator Return 1
4
NW 032273 Cable Assy,Prk Brk, 9 1
NW 031807 Cable Assy,Prk Brk,11 1
5
F101863 Ball Joint,ND,1/4-28, 2
6
39925 Brkt,Spring Return 1
7
39904 Brkt Wldmnt,Modulator 1
8
NW034690 Bar,Actuator,Modulator 1
9
203889 Rod,Throttle 1
10
41706 Brkt,Return Spring,60 1
11
NW021911 Spring,Carb Return 1
12
NW034717 Cable,Modulator,Felst 1
13
NW034718 Kit,Slip Link,Felsted 1
14
NW034731 Clip,Cable Mounting 1
15
NW034733 Shim 1
23
NW032055 Plate,Park Brake Lever 1
28
F100306 HHCS 5/16-18 X .75 4
29
F009546 Washer, 5/16 Lock 4
30
F009547 Nut Hex, 5/16-18 4
31
40435 Accelerator Linkage 1
Comm HHCS, 1/4-20 x 0.75 4
Comm Lock washer, 1/4 4
Comm Hex Nut, 1/4-20 4
32
F001005 E Pin Cotter 7/64 X 1 2
33
NW014718 Bearing 1
F009549 Flat Washer, 5/16 2
34
37616 Accelerator Pedal 1
Comm HHCS, 1/4-20 x 3.50 1
Comm Lock Nut, 1/4-20 1
Comm Flat Washer, 1/4 2
35
NW022971 Accelerator Pedal Bracket 1
Comm HHCS, 1/4-20 x 1.00 2
Comm Flat Waher, 1/4 2
Comm Lock Washer, 1/4 2
Comm Hex Nut, 1/4-20 2
36
F016985 HHCS, 3/8-16 x 3.50 1
Comm Hex Nut, 3/8-16 1
37
48624 Bar, Ext, Park Brk Cable P 1
NS
39220 Plate Shift Link (See Fig 62) P 1
NS
39903 Brkt, Brake Line Support (See Fig 10) P 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
