NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 267
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
112-
48385-5 Air intake Sys,M100,QSB3.3,T3 1
1
46604 Hood Air Cleaner, Plastic 1
2
45983 Band Mnt Air Cleaner 2
3
45982 Air Cleaner,9",Dual 1
4
48527 Ell,3" X 4"ID,Rubber 1
5
NW 033103 Clamp, T-Bolt,3.31-3.5 5
6
NW 035628 Clamp, T-Bolt,4.31-4.5 2
7
4852NW 034920 Clamp, Mu󰀪er,2.50" 1
NS
NW034819 Air Cleaner, CAT, M200 O 1
NS
NW032876 Pre-Cleaner Assy, CAT O 1
NS
NW035299 Band, Mnt, Air Cleaner, 11” O 1
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
112-
48385-6 Cooling Sys,M100,QSB3.3/C6/GM,T3 1
53425-6 Cooling Sys,M100,QSB3.3/GM T3 P 1
1
47231 Radiator/Oil/CAC 1
2
47235 Support Wldmnt Rad 1
3
44544 Reservoir,Coolant Overow 1
4
44556 Brkt Coolant Reservoir 1
5
45417 Decal Radiator Fill 1
6
NW031849 Hose Recovery Model 1
7
NW036097 Clip,Retain,Res Hose 1
8
F100669 Valve, Drain,1/4" 1
9
43459 Angle Mnt, Radiator 2
10
RF090504 Tbg Vinyl 0.43 X 0.06 62"
11
F101295 Ftg, Hyd,06MJ-10MB 2
12
F104402 Ftg, Hyd,06H-06FJX90 2
13
9.2066 Hose 0.37 ID Low Press 180"
14
203566 Isolator Rubber,Cntr 2
15
91926 Ftg, Hyd,08MJ-10MB90 2
16
NW034365 Ftg, Hyd,08MJ-12MP 2
17
46591 Hose,2.5",Flex Charge 2
18
48471 Ell,2.5",45 Deg,Flex 1
19
46592 Ell,2.5",90Deg,Flex 1
20
421808 Cut,4218, 10.50 1
21
48387 Tube,CAC,Top,100/140 1
22
48621 Strap,Rad Mtg,RH,100 1
23
38929 Bar,Strap,Rad,LH 1
24
NW033101 Clamp,T-Bolt,2.50-2.7 7
25
48474 Brkt,CAC Tube,Top,100 1
26
NW034920 Clamp, Mu󰀪er,2.50" 1
27
208967 Tube Rad,Junction 1
28
208945 Hose Rad,1.75 X Curve 2
29
NW036633 Hose Rad,1.25 X 19.12 1
30
48519 Shield,Dust,Lower Rad 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
