M100 Tow Tractor Manual No. 46052
PAGE 269
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
113-
48390-9 Steering Assy, M100 Hyd B3.3TAA/C6 T3 Ref
47385-9 Steering Assy, M100 Hyd QSB3.3/C6 T3
53535-9 Steering Assy, M100,Hyd, 41640-6 P
1
46420 Master Cylinder W/Booster 1
3
NW036560 Ftg, Hyd, 08MB-06MJ90 1
4
3.2519 Ftg, Hyd, 06MJ-08MB 3
5
F100979 Clamp Hose,#6,.44-.78 (79470),5406 10
6
F104402 Ftg, 06-06FJX90 2
7
1011081 Cylinder Steering 2B 7.4 ST 1
8
44738 Gauge Sight Plug,3/4 NPT (Lube Devices), LSP151-05-01 1
9
8796.50 Hose Assy, #6M 74.43", ST/90 2
10
41704 Hose Assy, PS, #6M, 31", ST/ST 1
11
1.7864 Steer Unit, 5.9 CI 1
15
NW026799 Ftg, Hyd,Ell,Press (01276), FF5300-0645 1
16
3.1572 Ftg, Hyd,06MJ-06MP (V00565) 2
17
F104418 Ftg, Hyd, Tee, Union 1
18
3.1564 Ftg, Hyd, 06MJ-06MP90 2
19
NW029020 Valve,Relief, Inline Adj,1100PS (V00534) 1
20
1008789 Ftg, Hyd, 08MJ-06MP 1
21
8949.19 Hose Assy, #8, 35”, ST/90 1
23
9.2066 Hose 0.37 ID Low Press 100”
24
38966 Reservoir Hyd, 1.75 GAL 1
25
202993 Breather,3/4 NPT,STL 1
26
46225 Brkt Hyd Tank 1
28
3.1391 Ftg, Hyd,Tee,06MP-06FP-06FP (V00565), 5602-06-06-06 1
29
46247 Ftg, Hyd,06H-06MP90 (V00565), 6/6/4501 1
30
46234 Angle Hyd Tank
31
NW034365 Ftg, Hyd,08MJ-12MP 1
32
46240.6 Hose Assy,#12L, 34",ST/ST 1
33
46094 Ftg, Hyd,12MJ-16MB (V00565) 1
34
91926 Ftg, Hyd,08MJ-10MB90 (V00565), 6801-08-10-NOW 1
35
F002691 Ftg,P,Tee,06 Mall 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
