NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 273
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
114-
48390-3 Elect Assy, M100, B3.3TAA/C6 T3 Ref
48385-3 Elect Assy, M100, QSB3.3/C6 T3
53425-3 Elect Assy, M100, QSB3.3/GM T3 P
53535-3 Elect Assy, M100, B3.3TAA/C6 T3 P
1
3.1820 Ftg, Hyd,Tee,02MP-02FP 1
2
3.3329 F,Nut,Hex,M6 X 1.0, 1
3
37733 Clip,Insul,.62 ID 2
4
47780 Harness Eng,CMNS,B3.3 1
50153 Harness Eng,CMNS,QSB3.3
5
F010907 Ftg, 06MP-02FP,BRASS 1
6
F101115 Clip, Insul,.44 ID 3
7
NW030236 Sender,Temp, Hi-Range 1
8
F101527 Sender,Oil Press,0-100 1
9
F101680 Clip,Iinsul,1.75 ID 1
10
F102160 Relay, Starter,12V 1
11
F103925 Nut, Hex,M10X1.5P,GR8.8 1
12
F016765 F,RHMS,#10-32 X 3/4,Z 1
13
NW010518FB Strap, Ground,4 GA X 1
14
NW 021649 Switch Oil Pressure 1
15
NW 030236 Sender,Temp,Hi-Range 1
16
3.3197 HHCS,M10 X 1.50 2
17
50155 Harness Starter Cummins 1
18
44236 Harness rear,C6 1
19
41528 Ftg, Hyd,M10MB-02FP 1
20
38733 Ftg, Hyd,02MP-02FP 1
21
41529 Washer,O-ring,M10 1
22
42980 Harness Ground Wire 1
23
44243 Schematic,Elec,Cummins 1
24
46484 Schematic,Elec,M100 1
25
2.3267 Cable,Welding,Neoprene 63
26
2.3359 Terminal,Battery,Neg 1
27
2.3274 Terminal, Ring,3/8 1
28
2.3373 Terminal, Ring,7/16 1
29
RF 090896 Sleeve Alum Fiberglass 40
30
200084 Fuse, 20A/32V,ATC 1
31
46036 Cable Assy, Ground, Cummins 1
32
NW 035385 Insert,Switch,Glo Plug 1
33
NW 035382 Insert,Switch,Blank, 1
34
NW 035378 Housing,Light Indicator 1
35
NW 035374 Switch,Rocer,O󰀨-MOM 1
36
50113 Relay,Power,SPNO,12VD 1
37
47862 Fuse,300A/48V,MEGA/AMG 1
38
305007 Holder,Fuse,MEGA/AMG 1
39
50144 Plate,Relay/Fuse Mnt 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
