NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 281
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
115-
45796-1 Eng/Trans Mntg,M100,Deutz BF4M2012E/C6 Ref
1
305758 Adapter Hub, C6, 0030-2154 1
2
305757 Flywheel with Ring Gear - D4/C6, 2200-1771 1
3
305760 Washer Plate, Engine D4/C6, 0115-1184 10
4
Flexplate (supplied with transmission) 1
5
305759 Bolt M16 x 35, 0111-2679 3
6
42965 Hex Flange Head M10x.63 (0AT39), 3910665 4
7
Nut (supplied with transmission) 8
9
NW034441 Trans, C6, 3 spd, 2.40 SR w/ Brake, XUIL-7000-BAPR 1
10
305762 Dowel 1/2 x 1, Transmission D4/C6, 0030-2112 2
16
Housing Adapter, 0030-2110 1
17
43365 Torque Converter, C6HD (39569),EATP-7902-BB 1
49
F100340 HHCS, 7/16-14x2.25 6
F18486 Washer 7/16 Lock 6
50
Comm HHCS 1/4-20x2.75 2
F9704 Washer, 1/4 Flat (both sides) 4
F13588 Nut 1/4-20 Nylok 2
51
F100320 HHCS, 3/8-16x2.75 1
F9665 Washer 3/8 Lock 1
52
122077 HHCS, 5/16-18x2.5 (insert from engine side) 1
F9546 Washer, 5/16 Lock 1
72
NW036501 Yoke Flange 1
73
41072 Bolts 4
74
41073 Strap 2
84
42856 Dipstick 1
85
44075 Tube, Dipstick C6, EOPZ-7A228-A 1
86
302313 Pan, Oil 1
87
37920 Gasket, Oil Pan, C6 1
88
NW034532 Filter, Transmission 1
90
37588 Support Wldmnt, Trans 1
NS
44112 Kit, Flywheel Adapter Deutz/C6 (Kit includes items 2, 4, 5,
8, 9, 10), 999-0297
1
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
