NMC-WOLLARD 100 - Page 525

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 287
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
118-
42320-4 Cooling Sys, M100 D4/C6 Ref
1
42327 Radiator, D4 (0J567) 1
2
RF090504 Hose, Radiator 16
3
38929 Bar, Strap, Rad, LH (4 Cyl) 2
4
SW1H1007 Clamp, Hose 2
5
41698 Hose, Heater 1.00" 24"
6
F101140 E-Clamp, Hose, #32, 1.56 - 2.50 8
7
41703 Hose, Radiator, Lower 1
8
41233 Tube, Coolant, .65W x 2 OD x 4" 2
9
37655 Cooler, Oil, Trans 1
10
42376 Bar Weldment, Oil Cooler Mounting 1
11
NW024714 Valve, Check 7/16-20 1
12
42386 Shroud, Fan, D4 1
13
NW035477 Hose, Coolant, 76” 1
13A
NW027605 Hose, Coolant, 82” 1
14
41679 Hose, Radiator, Upper 1
15
Comm Clamp 2
16
NW021635 Hose .75 ID Heater A/R
17
NW010325A Insulator, Engine Mount, Rubber (57839), K5160DURO 2
18
152864 Horn 1
43413 Bracket, Horn 1
19
F101745 Grommet (Lakeview Industries), 11487B600 1
20
301304 Hose, Radiator, Lower (D4) 1
21
38086 Cap, Radiator 1
22
NW034736 Ftg, Hyd, Tee, 04MP-04FP-04FP 1
23
NW034736 Ftg, Hyd, 06H-04MP90 1
24
F104402 Ftg, Hyd, 06H-06FJX90 1
25
3.1571 Ftg, Hyd, 06MJ-04MP 1
26
F009546 LW 5/16 8
F009547 Nut, Hex, 5/16-18 8
27
Comm HHCS 5/16-18 x 3/4 4
28
43450 Hose 1
29
42051 Fitting, Hose, Barb, 3/8 x 1/4 NPT 1
30
Comm 1/4 NPT Plug 1
31
44544 Reservoir, Coolant Overow (ONYTB),BVR-4 1
32
40164 Cap, Reservoir (34669), 68 1
33
44556 Brkt, Coolant Reservoir 1
34
Comm THMS, 5/16-18 x 1 2
35
Comm Washer, 5/16 2
36
Comm Nut, 5/16-18 Nylock 2
NS
43459 Angle, Mntg, Radiator 1
NS
41656 Angle Wledment, Rad 1
NS
44155 Ftg, P, 12MP-10H, Brass 1
NS
44032 Ftg, Hyd, 26MM-12FP 1
4 ILLUSTRATED PARTS LIST
AUGUST 31, 2008
