M100 Tow Tractor Manual No. 46052
PAGE 319
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
132-
46200-1 Perkins Engine Pack 1104-44 T2/C6 Ref
31
F103925 Nut, Hex 4
32
43693 Plate, Flywheel Assembly (V00517) 13500038 1
33
Comm HHCS 1/2-20 GR 5 6
34
43365 Converter Assembly EATP-7902-BBPR 1
35
NW034441 Transmission, C6 XUIL-7000-BAPR 1
NW034678 Ring Gear, 126 Teeth 1
36
43269 Bracket, Dipstick 1
38
43694 Flywheel Assy w/ Ring Gear (V00517) 1
NW034678 Ring Gear For Flywheel, 126T 1
49
F100444 Pin Dowel 2
50
43695 Flywheel Housing (V00517) 10500008 1
51
43361 Flywheel, Ford 6375A 1
43362 Reinforcing Plate, Flywheel 1
52
43363 HHCS, 7/16-20 x 13/16 6
53
NW031820 HHCS, M12-1.75 x 38 (at top) 2
54
Comm Washer, M12 Lock 2
55
204730 HHCS, M10-1.50 x 35 6
56
3.3326 Washer, M10 Lock 6
57
F100403 HHCS, 1/2-13 x 1.5 12
58
F015973 Washer, 1/2 Lock 12
59
F016102 SHCS, 5/16-18 x 1.25 (on inside) 1
F100308 SHCS, 5/16-18 x 1.50 (bottom center) 3
60
F009704 Washer, 1/4 (for above) 2
61
F100622 HHCS, 7/16-20 x 2.0 6
62
F018486 Washer, 7/16 Lock 6
75
NW036501 Yoke Flange 1
76
41072 Bolts 4
77
41073 Strap 2
78
42856 Dipstick 1
79
44075 Tube, Dipstick C6 EOPZ-7A228-A 1
80
302313 Pan, Oil 1
81
37920 Gasket, Oil Pan, C6 1
82
NW034532 Filter, Transmission 1
83
NW034205 Support Wldmnt, Trans 1
84
37188 Trans. Mount. C6 1
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2009
