NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 327
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
136-
46200-7 Cooling System, Perkins 1104-44 T2/C6 Ref
10
NW031849 Hose, Recovery, Vinyl, 55" 1
10A
NW036097 Clip, Retaining, Res Hose 1
10B
F101007 Clip, Insul, .62 ID 1
11
42151 Hose, Radiator, 2.00x16.5 1
12
F101140 Clamp, Hose, #32 4
13
40340 Hose, Rad, Reducer, 1.75 ID x 2 2
14
42533 Shroud, Fan (0J567) 1
17A
NW035477 Hose, Coolant, 76” 1
17B
NW027605 Hose, Coolant, 82” 1
18
38344 Hose, Radiator, 2 x 9.5 1
19
152864 Horn (V00544), 7200021 1
19A
43413 Horn Bracket 1
21
F100979 Clamp, Hose, #6 4
22
39484 Plate, Oil Cooler, C6 2
24
37676 Strap, Mount, Oil Cooler 2
25
37655 Cooler, Oil, C6 Trans 1
26
38077 Bracket, Radiator Upper 2
28
37576 Radiator, w/Cap (0J567), 11364 1
NW017243 Radiator Cap (1HS72), 3781830 Ref
29
37795 Angle, Radiator Support, Bolt-on 1
30
F009546 Washer, 5/16 Lock 1
31
F100306 HHCS, 5/16-18 x .75 1
32
44544 Reservoir, Coolant Overow (ONYTB), BVR-4 1
33
40164 Cap, Reservoir (34669), 68 1
34
44556 Brkt, Coolant Reservoir 1
36
38615 THMS, 5/16-18 x 1 2
37
F006549 Washer, 5/16 2
38
F014476 Nut, 5/16-18 Nylock 2
39
F101146 Clip, Insul, 1.25 ID 1
50
NW034729 Ftg, Hyd, Tee, 04MP-04FP 1
51
NW034736 Ftg, Hyd, 06H-04MP90 1
52
F104402 Ftg, Hyd, 06H-06FJX90 1
53
3.1571 Ftg, Hyd, 06MJ-04MP 1
54
NW030236 Sender, Temp 1
NS
NW032352 Ftg, 08MP-10H 1
NS
NW035476 Hose, Coolant, 54” 1
NS
RF090504 Tbg, Vinyl, .43 x .06W 62”
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2009
