NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 333
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
139-
46200-2 Elec Assy, Perkins 1104 T2/C6 Ref
3.3329 Nut, Hex,M6 X 1.0,ZC 1
37733 Clip,Iusul,.62 ID, .53 HOLE, COV 1117 2
46248 Harness Eng,1104 1
45745 Schematic,Elec,1104 (See Chap 2) 1
38733 Ftg, Hyd,02MP-02FP 1
F016765 RHMS,#10-32 X 3/4,ZC 1
3.0556 Ftg,P,08MP-02FP,BRASS 1
F101115 Clip Insul,.44 ID, .41 HOLE, COV 0813 3
F101680 Clip,Insul,1.75 ID, .41 HOLE, COV2913ZI 1
F102160 Relay Starter,12V (V00549), F498 1
F103925 Nut, hex,M10X1.5P,GR8.8,ZC*NS, MNC5 1
3.3197 HHCS,M10 X1.5M,GR8.8 2
NW031487 Nut, Hex,M5 X 0.8,ZC *NS* 1
NW031776 Harness Starter 1
F101527 Sender,Oil Press,0-100#,1/8NPT (V00542), 02505-00 1
NW021649 Switch, Oil Press,Hourmeter (13445) 1
NW030236 Sender,Temp,Hi-Range,1/4 NPT (8S377), 02023-00 1
NW036429 Harness, Rear,C6 1
F101526 Sender, Temp Hi-Range,1/8 NPT (8S377), 02022-00 1
NW010518FB Strap, Ground,4 GA X 9" (59587) 1
3.1820 Ftg, Hyd Tee,02MP-02FP-02FP (V00565) 1
2.1401 Relay, Power, SPNO, 12VDC 1
2.3345 Fuse, 30A/32V, FNM 1
2.3346 Holder, Fuse, 30A 1
37540 Plug, Assy, Elec 1
RF090896 Sleeve Alum Fiberglass 2.50 40”
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2009
