NMC-WOLLARD 100 - Page 573

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 335
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
140-
45907 Steering Assembly, M100, Hyd/C6
1
49008 Column, Steering, 10” w/wire spring I 1
NW035372 Column, Steering, 10” w/wire spring J 1
152283 Tie, Cable 11.88”, 50# 2
2
F104402 Fitting, Hyd., Ell, 06H-06FJX90 1
3
NW036560 Fitting, Hyd.,Adapter, Ell, Adj. 1
4
3.2519 Fitting, Hyd., Connector, ST 3
5
F100979 Clamp, Hose #6, .44 - .78 8
6
3.1564 Fitting, Hyd., Adapter, Ell 2
7
1011081 Cyl Steering, 1" Shaft, 7.4 Stroke (0ZK80), 2513 1
1012065 Seal Kit, Steering Cylinder 1
8
NW034968 End, Tie Rod, 3/4-16, RH 40-60 (0AT39), 06-60360 2
9
8796.50 Hose Assy., #6M, 74.43” 2
10
41704 Hose Assy., Power Steering #6M, 31¨, ST/EL 1
11
42042 Orbitrol, Steering (96151), 211-1007 1
12
NW036491 Wheel, Steer, Eaton, Column 1
13
150526 Nut, Steering, Hyd. 1
14
202736 Button, Horn Kit 1
15
NW026799 Fitting, Hyd. Adapter, Ell, Pressure 1
19
NW029020 Valve, Relief, Inline (V00534), 9-2-3-1100PSI 1
35
F104418 Fitting, Hyd. Adapter, Tee, Union 1
39
152495 Nut, Hex, 3/4-16, Jam 2
NS
45937 Support Wldmnt, Rear 1
NS
306346 Nutsert, 1/4-20 3
NS
45592 Cover Wldmnt, Steering 1
4 ILLUSTRATED PARTS LIST
APRIL 15, 2012
