M100 Tow Tractor Manual No. 46052
PAGE 365
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
152-
46500-1 Eng/Trans Mntg Assy, Zenith, Z644/C6 1
46500-3 Linkage Assy, Zenith, Z644/C6 1
1
46496 Engine/Trans, Z644/ C6 1
2
47232 Support Wldmnt, Trans, 100, Z4.4L 1
3
46693 Brkt Wldmnt, Eng Mtg, RH, 100, Zenith 1
4
46678 Brkt Wldmnt, Eng Mtg, LH, 100, Zenith 1
5
46688 Brkt Wldmnt, Eng/Frame, RH, 100, 28"W 1
6
46702 Brkt Wldmnt, Eng/Frame, LH, 100, 28"W 1
7
46781 Brkt Wldmnt, Shift Cable, 100, Zenith 1
8
37357 Isolator, Rubber, Engine (V00501), 17/0566-45 2
NS
NW031807 Cable Assy, Park Brake, 11.75" (92867), 16567901 1
NS
37646 Bar, Ext, Park Brake Cable 1
NS
46791 Lever Wldmnt, Shift, C6, 100, Zenith 1
NS
44940 Angle Dipstick Mnt, C6 1
NS
46673 Driveshaft, 8.25, 1410, Slip, C6 (See Fig 154) 1
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
152-
46501-1 Eng/Trans Mntg Assy,Z644LP/C6 1
1
46497 Eng/Trans,Z644LP/C6 1
2
46689 Support Wldmnt, Trans,C6,M100 1
3
46693 Brkt Wldmnt, Eng Mtg,RH,100,ZENITH 1
4
46678 Brkt Wldmnt, Eng Mtg,LH,100,ZENITH 1
5
46688 Brkt Wldmnt, Eng/Frame,RH,100,28"W 1
6
46702 Brkt Wldmnt, Eng/Frame,LH,100,28"W 1
8
37357 Isolator, Rubber, Engine (V00501), 17/0566-45 2
NS
44940 Angle Dipstick Mnt,C6 1
NS
41937 Driveshaft,TA268/C6,11.0-12.5 (95019)(See Fig 116),
912459-0114
1
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
152-
52284-1 Eng/Trans Mntg Assy,Z644LP/C6 O 1
53405-1 Eng/Trans Mntg Assy, Z644LP/GM P 1
1
49691 Engine,Z644LP/C6 1
NW034441 Trans, C6, 123, 2.30SR, W?Brake1 1
2
46689 Support Wldmnt, Trans,C6,M100 1
3
46693 Brkt Wldmnt, Eng Mtg,RH,100,ZENITH 1
4
46678 Brkt Wldmnt, Eng Mtg,LH,100,ZENITH 1
5
46688 Brkt Wldmnt, Eng/Frame,RH,100,28"W 1
6
46702 Brkt Wldmnt, Eng/Frame,LH,100,28"W 1
8
37357 Isolator, Rubber, Engine (V00501), 17/0566-45 2
NS
44940 Angle Dipstick Mnt,C6 1
NS
41937 Driveshaft,TA268/C6,11.0-12.5 (95019)(See Fig 116),
912459-0114
1
NS
37535 F,FW, 0.66ID, 3.12OD 2
NS
52283 Support, Wldmnt, Trans, 100, Z4.4L 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
