M100 Tow Tractor Manual No. 46052
PAGE 375
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
157-
46500-4 Exhaust Sys Zenith, Z644/C6 1
1
46703 Mu󰀪er,RD,6.62X18,2.5"I/L&O/L, M065140 1
2
46721 Pipe,Exh,Y-Wldmnt,100,Zenith 1
3
46725 Pipe,Exhaust,I/M,100,Zenith 1
4
46726 Pipe,Exhaust,O/L,100,Zenith 1
5
Catalytic Converter 1
6
46194 Brkt,Exhaust Hanger 1
9
NW034920 Clamp,Mu󰀪er,2.50 DIA, 510250 5
7
NW023112 Hanger,Tail Pipe,JG40PT15, TPH24 2
8
NW018924 Hanger,Wldmnt,Mu󰀪er,6.62"*B* 1
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
157-
52284-4 Exhaust Sys Zenith, Z644/C6 O 1
1
41365 Mu󰀪er,2.5” x 6.62” x 20 1
2
51801 Pipe,Exh,Y-Wldmnt,100,Zenith 1
3
52277 Pipe,Wld, Exh, Crossover 1
4
51754 Pipe,Exh, Tail, 2.5” x 14, 140Z 1
6
47285 Brkt,Exhaust Hanger 1
7
NW023112 Hanger,Tail Pipe,JG40PT15, TPH24 2
8
NW018924 Hanger,Wldmnt,Mu󰀪er,6.62"*B* 1
NS
52278 Gasket, Flg, 2.5 ID x 3.88 5
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
157-
53405-4 Exhaust Sys Zenith, Z644/C6 P Ref
1
46703 Mu󰀪er, RD, 6.62x18.2 1
2
48484 Pipe Wld Exhaust, I/M 1
3
46721 Pipe, Exh, Y-Wldmnt 1
4
53375 Pipe, Exh, 2.5” x 29” 1
6
46194 Bracket, Exh Hanger 1
7
NW023112 Hanger, Tail Pipe 1
8
NW034920 Clamp, Mu󰀪er, 2.50” 5
NS
53376 Flange Wld Exh 100ZLP 1
NS
47619 Heat Shield Wld 1
NS
47285 Hanger, Exhaust, Strap 1
