M100 Tow Tractor Manual No. 46052
PAGE 379
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
159-
46500-2 Elect Assy Zenith, Z644/C6, M100 Ref
52284-2 Elect Assy Zenith, Z644/C6, M100 O
53405-2 Elect Assy Zenith, Z644/GM, M100 P
1
46757 Insert,Switch,Eng Run,GN, 594500 1
2
45143 Insert,Switch,Eng Stop,Red, SPR 595 429 1
3
45164 Insert,Switch,Eng Warning,YLW, 00900.166 1
4
46758 Insert,Switch,Battery,Red, 596153 1
5
NW035390 Iinsert,Switch,Low Oil PSI,Red, 596 171 1
6
NW035388 Insert,Switch Brake Fault Red, SPR130-0094-00 1
7
NW035380 Frame 3 Switch (65439), 595502 SPRAGUE 1
8
NW035378 Housing,Light Indicator,2-Lamp (Advance), SPR 511 502 3
NS
37409 Conn Light (65439), SPR 913 328 6
NS
46498 Harness Engine,Z644 1
NS
44236 Harness Rear,C6,22 PIN CONN 1
NS
NW030236 Sender, Temp,Hi-Range,1/4 NPT (8S377), 02023-00 1
NS
3.1820 Ftg,Hyd,Tee,02MP-02FP-02FP (V00565), R99JT05500 1
NS
F102160 Relay,Starter,12V (V00549) (See Fig 40), F498 1
NS
46796 Brkt,Relay/Fuse,100,Zenith 1
NS
F101597 Light,Gauge,Non-Shutdown (16476), 06215-00 3
NS
NW010518FB Strap,Ground,4 GA X 9" (59587) 1
NS
44840 Pedal,Accel,Blkhd,Cummins Elec, WM540-131507 1
NS
46873 Harness,Dash,Gauge/Light 1
NS
46872 Harness,Dash, Indicator Lights 1
NS
F101527 Sender, Oil Press, 0-100 PSI O 1
NS
46796 Brkt, Relay Fuse O 1
NS
F101597 Light, Gauge, Non-Shutdown O 3
NS
48483 Wiring Diagram 100/60 P 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
