NMC-WOLLARD 100 - Page 619

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 381
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
160-
46500-9 Steering Assy, 100, Hyd, Zenith, Z644/C6 1
2
F104402 Ftg,Hyd,06H-06FJX90 (01276), 33982-6-6 1
3
NW036560 Ftg,Hyd,,08MB-06MJ90 (V00565), P80JT07200 1
4
3.2519 Ftg,Hyd,,06MJ-08MB (V00565), A40ZI36001 3
5
F100979 Clamp, Hose #6,.44-.78 (79470), 5206 2
6
3.1564 Ftg,Hyd,,06MJ-06MP90 (V00565), T55JS05620 2
7
1011081 Cyl,Steer,2B 7.4S 1R (0ZK80), 2513 1
9
8796.50 Hose Assy,#6M, 74.43",ST/90 2
10
41704 Hose Assy,PS,#6M,31",ST/EL, D13ZI36540 1
11
42042 Steer Unit,4.5CI,OC,NLR, 211-1007 1
14
202736 Button,Horn,For VIP Wheel 1
15
NW026799 Ftg,Hyd,,Ell,M18MX-06FJX90 (01276) 1
16
46769 Ftg,Hyd,,Ell,M16MX-06FJX90 1
23
9.2066 Hose 0.37 ID LOW PRESS (01276), G13KG50030 100
35
F104418 Ftg,Hyd,,Tee,Union, 29T6 1
37
NW036491 Wheel,STeer,16",Eaton Column, 16353BP 1
39
150526 Nut,Hex,13/16-20,Steering*NS, 1741 1
41
49008 Column,Steering,10" W/wire ag I 1
NW035372 Colun,Steering,10" W/wire spring J 1
44
NW034968 End,Tie Rod,3/4-16,RH,40-60 (0AT39), 06-60360 2
NS
152495 Nut,Hex,3/4-16,JAM,ZC 2
NS
306346 Nutsert,1/4-20,.165-.260,Open, AKS4-420-260 3
NS
45592 Cover Wldmnt,Steering Dash 1
NS
46747 Pedal Wldmnt Brkt,60/100 1
NS
46867 Decal,Power Steer Pump Fill,RH 1
NS
46762 Support Hood Wldmnt P 1
NS
41640-5 Axle, Front, Rear Cyl P 1
NS
52280 Plate, Deck, 100 P 1
NS
202735 Wheel, Steer 14” Eaton P 1
NS
45589 Decal, Power Steer P 1
NS
48481 Hose Assy PS P 1
4 ILLUSTRATED PARTS LIST
MARCH 08, 2016
