NMC-WOLLARD 100 - Page 621

NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 383
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
161-
46501-8 Fuel Sys,Z644LP/C6 Ref
47483 Grp, M100, LP Tank, Fender Mnt
44320 Grp, M100, LP Tank, W/Car
44321 Grp, M100, LP Tank, W/O Cab O
0
308745 Fuel System,ZPP420,LP,888 1
1
F102521 Tank,LP,33 1/2# Not Aluminum(V00552), 5570 1
2
F102519 Brkt Set,TB-2 Tank 1
3
F103131 Coupler,LP,Female, 7141F 1
4
46834 Hose Assy,LP,#6 ,24.0",ST/ST 1
41767 Hose Assy,LP,#6 ,45.0" (for 44320 only) 1
5
200546 Ftg, Hyd,06MJ-04MP90, A40JT30620 1
6
46776 Valve,Relief,Hydrost,375 PSIG, 3127K 1
7
F103148 Ftg, Hyd,04FP-04-04BKHD, T-444 1
8
46835 Hose Assy,LP,#6 ,21.0",ST/ST 1
9
F100979 Clamp Hose, #6 11
10
NW031945 Ftg,Y,10H-10H-10H,Plastic 2
11
9.0027 Hose, Heaer AR
12
3.1571 Ftg,Hyd,06MJ-04MP (V00565), T55JS03702 2
13
Fuel Lock Valve 1
14
Vaporizor 1
15
F103146 Ell 3/8MP X 5/8 Hose .44-.78 3
16
F103316 Hose, 1.00 ID Vapor 2
17
F101161 Clamp, Hose, #16, .81 X 1.50 4
18
NW030246 Ell, 90D, 1 X 1 1
19
Regulator, Maxtrol, 1 PSI, R600Z 1
22
Mixer Bowl, E330 1
23
9.1799 Hose, 24”X1/4 Vacuum AR
24
46848 Wldmnt, LP Regulator 1
NS
NW028246 Hose Assy, 60” O 1
4 ILLUSTRATED PARTS LIST
NOVEMBER 02, 2015
