NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 5
CHAPTER 5 MAUFACTURER’S INFORMATION
iii
• About
The 2" Stand-Alone CAN Display instrument is a member of the Beede
NexSysLink® CAN instruments product family�
This instrument directly reads SAE J1939 compliant CAN messages and
displays the message information on a sunlight visible, transective dot-
matrix LCD� Like all NexSysLink® instruments, this product eliminates the
need for a translation “black box” between an ECM/ECU and the instrument
itself making wiring and installation simple and fast�
Three discrete alert LEDs provide users with visual notication of engine/
vehicle/vessel parameter faults, warnings and malfunctions�
Built-in, sealed, tactile switches allow users to easily navigate the intuitive
menu driven user interface� The integration of the switches also reduces
wiring to further reduce installation time and costs; essentially providing a
plug-and-play product�
Although designed to "stand-alone", the instrument may be used
in conjunction with other NexSysLink® instruments to monitor your
equipment�
• Scope
This manual describes how to navigate the LCD interface and use the many
features the instrument provides� Although the interface is intuitive and
easy to navigate, this operation manual provides users with a resource to
realize the full potential and capabilities of the instrument�
Covered in this manual are display options, menu navigation and menu
function usage�
Although some wiring connections are noted for easy reference, this
manual does not cover complete installation mounting and wiring
requirements� Please refer to the installation instruction sheet for proper
installation�
NexSysLink
®
2" Stand-Alone CAN Display Operation Manual SAE J1939
CAN DISPLAY MANUAL
NOVEMBER 02, 2015
