M100 Tow Tractor Manual No. 46052
PAGE 91
CHAPTER 5 MAUFACTURER’S INFORMATION
C-6 TRANSMISSION PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E󰀨 Units
Per
Assy
1 302281 E7TP-CA Case Assembly, Standard Trans. 1
2 38792 E4TP-EA Converter, Torque (1.87:1) (used
with case #E7TP-CA)
1
43365 Converter, Torque, 2.36:1
307413 Converter, Torque, N-W Standard
3
NS
NS
302282
COMM
COMM
D0TZ-7085-A
33846-S8
34944
Retainer, Rear Bearing (incl. Item
#4)
Nut, 1/2-20
Washer, Tooth Lock, 1/2
1
4
4
4 302283 D0TZ-7A011-A Seal, Output Shaft Oil 1
5 302284 D3TZ-7089-B Yoke, Output 1
6 302285 C8HZ-7A002-A Plug, Speedometer Drive Hole 1
7 NOT USED
8 Comm 20522-S HHCS 5
9 Comm 351487-S Washer, Tooth Lock 5
10 302286 D1TZ-17285-A Gear, Speedometer (used as spacer) 1
11 302287 D2AZ-7B426-A Gasket, Throttle Control Diaphragm 1
12 302288 D0TZ-7086-A Gasket, Bearing Retainer 1
13 302289 D5TZ-7070-A Snap Ring, Rear Bearing 1
14 302290 8D-7065 Bearing, Rear 1
15A
15B
Comm
Comm
380209-S
380207-S
HHCS, 3/8-16 x 1.25
HHCS
2
4
16 302291 D0TZ-7A039-B Extension Assembly (includes studs) 1
17 302292 D0TZ-7086-A Gasket, Extension Housing 1
18 302293 87650-S Plug, Dry Seal Tapered Thread,
1/8-27”
3
19 302294
302295
E0UZ-7D273-A
or
D7AZ-7D273-B
Fitting, Oil, 1/4-18 male x 1/2-20
female
Fitting, Oil, 1/8 male x 1/2-20
female
2
2
20 302296 D0AZ-7034-B Vent, Case 1
21 302297 C6AZ-7C232-A Sleeve, Oil Distributor 1
22 Comm 58618-S2 HHCS, 5/16-28 x 1.00 4
23 302298 377138-S Ring, Retainer (copper) 1
24 302299 C7AZ-7D220-A Body, Governor Oil Collector 1
25 302300 D8AZ-7C063-B Body Assembly, Governor 1
25A 302301 C4AZ-7D218-B Retainer, Governor Secondary
Valve Spring (not shown)
1
JANUARY 31, 2007
