NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 97
CHAPTER 5 MAUFACTURER’S INFORMATION
C-6 TRANSMISSION PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E Units
Per
Assy
1 302334 F0TZ-7D411-A Rod, Parking Pawl Actuating
(Includes item #24)
1
2 Comm 97411-S Retainer 1
3 Comm 376562-S Screw 1
4 302335 E0TZ-7A261-A Spring, Manual Control Valve Detent
Lever
1
6 302336 D2ZP-7A256-AB Lever Assembly, Manual Control 1
7 302337 D5AZ-7B498-A Seal Assy, Manual Control Lever 1
8 302338 E0TZ-7A115-A Lever Assy, Manual Control Valve
Detent
1
9 302339 D0AZ-7D261-B Lever Assy, Downshift Detent Inner 1
10 Comm 33945-S Nut 1
11 302340 EAA 6572-A Cup, Parking Plate Shaft 1
12 302341 C6AZ-7D418-A Shaft, Parking Plate 1
13 302342 C9AZ-7D417-A Spring, Parking Brake Torsion 1
14 302343 C9AZ-7D414-A Plate Assy (includes item #13) 1
15 Comm 33798-S Nut 1
16 Comm 34806-S7 Washer, Lock 1
17 302344 D0OZ-7A394-B Lever, Downshift Control Outer 1
18 302345 386078-S Seal 1
20 302346 E0TZ-7A441-A Pawl, Parking 1
21 302347 C6AZ-7D070-B Spring, Parking Pawl Return 1
22 302348 C6AZ-7D071-A Shaft, Parking Pawl Return 1
23 Comm 379058-S7-8 Screw and Washer 1
24 NSS E0AP-7D419-BA Plate (see item #1) 1
25 302349 D3TZ-7B368-A Washer, Output Shaft Thrust Rear 1
26 302350 D6TZ-7A233-A Gear, Output Shaft (incl item #25) 1
27 NW35944 D2ZZ-7A247-C Neutral Switch Assembly 1
JANUARY 31, 2007
