M100 Tow Tractor Manual No. 46052
PAGE 155
CHAPTER 5 MAUFACTURER’S INFORMATION
172 (6.8)287 (11.3)
PRM MARINE LIMITED
DO NOT SCALE,
ALDERMAN'S GREEN IND. EST .
612B/612PB AXLE INSTALLATION
19/02/2014
1:1
612B/PB INST
21
BY
of
MOD NoDATE
MODIFICATION DESCRIPTION
ISS
PART No:TITLE:
SHEET SIZE: MATERIAL: HEAT TREATMENT: ISSUE:
SIGNED: SIGNED
DATE:SCALE:STATUSSHEET No:
APPROVED:
A0
WHOLE DIMENSIONS =
COVENTRY CV2 2LD
DRAWN:
THREADS TO MEDIUM FIT (6H G6),
GENERAL M/C FINISH Ra 6.3,
DIMENSIONS IN mm U.O.S.,
PART No:
Web: www.prm-m arine.com Email: design@prm -marine.com
DECIMAL DIMENSIONS = ±0.25
IF IN DOUBT ASK!
PROTOTYPE
A
D. MOORE
612B/PB INST
PART No:
B
A
C
D E F
G H
J
K
L
M N P Q R
A
B C
D E F
G H
J
K
L
M N P Q R
21 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
2019181716151413121110987654321
1:1
1
of
MOD NoDATE
MODIFICATION DESCRIPTION
ISS
PART No:TITLE:
SHEET SIZE: MATERIAL: HEAT TREATMENT: ISSUE:
SIGNED: SIGNED
DATE:SCALE:STATUSSHEET No:
APPROVED:
A0
ANGULAR DIMENSIONS = ±.050°
DO NOT SCALE,
DRAWN:
Fax: +44 (0)24 7661 1845 Tel: +44 (0)24 7661 7141
BREAK ALL SHARP EDGES
PLEASE INFORM OF ANY ERRORS
DIMENSIONS IN mm U.O.S.,
GENERAL M/C FINISH Ra 6.3,
DECIMAL DIMENSIONS = ±0.25
IF IN DOUBT ASK!
ANGULAR DIMENSIONS = ±.050°
THREADS TO MEDIUM FIT (6H G6),
WHOLE DIMENSIONS =
BREAK ALL SHARP EDGES
PLEASE INFORM OF ANY ERRORS
BARLOW ROAD
THIS DOCUMENT IS CONFIDENTIAL AND IS THE PROPERTY OF PRM MARINE LIMITED. IT IS SUPPLIED ON THE EXPRESS CONDITION THAT IT MAY NOT BE LOANED, COPIED OR DISCLOSED TO ANY THIRD PARTY AND MUST BE RETURNED ON DEMAND.
C
L
C
L
NOTE:
MAXIMUM DRAWBAR PULL 53,400N (12,000 lbft)1. RATIOS AVAILABLE 20:1, 16:1 & 13:12. LUNRICATING OIL 80w/90 GEAR OIL OR EQUIVALENT IN AMBIENT TEMPERATURES 0-30
C (32 - 86F)3.
ESTIMATED OIL CAPACITY 11.5 LITRES (24.3 US PINTS)4. ESTIMATED DRY WEIGHT 300 Kg5. AXLE SUPPLIED WITHOUT WHEEL NUTS6.
SUIT CUSTOMER REQUIREMENTS LEVER CAN BE ROTATED TO
PARK BRAKE DETAIL VIEW
SCALE 1:2
69.85 (2.75)
C
L
C
L
C
L
BRAKE FEED
OIL DRAIN PORT
BRAKE BLEED TYP
C
L
HS1410 DRIVE FLANGE
208 (8.2)
30 (1.2) DISC
11.20 (0.44) THRO
336 (13.2) MAIN CASE DIAMETER
4 HOLES
THICKNESS
312 (12.3) DISC DIAMETER
412 (16.2) MAIN CASE WIDTH
336 (13.2)
CASE DIAMETER
C
L
BREATHER VALVE
OIL FILL PORT
C
L
1219 (48) TRACK WIDTH
560 (22) 612PB OVERALL LENGTH
1284 (50.6) OVERALL WIDTH
350 (13.8) MIN CALIPER CLEARANCE
460 (18.1) 612B OVERALL LENGTH
189 (7.4)
96 (3.8)
NOTE: NO MOUNTING CENTRES SHOWN. CUSTOM CENTRES AVAILABLE ON REQUEST. MOUNTINGS DETAILED ON SHEET 2.
C
L
8 STUDS 9/16 x 18 UNF - 3A
ON 165.1 (6.5) PCD AS STANDARD
8 STUDS M20 x 1.5 ON
275 (10.83) PCD ALSO AVAILABLE
C
L
122.25 (5.5)
WHEEL SPIGOT
NOTE: 0 INSTALLATION ANGLE SHOWN
REFERENCE VIEW
NOT TO SCALE
MAY 15, 2016
NEWAGE AXLE
