M100 Tow Tractor Manual No. 46052
PAGE 22
CHAPTER 2 MAINTENANCE
1 SERVICING
APRIL 15, 2012
IMPORTANT! Clean brake system rubber parts in clean, denatured
Your inspection should be thorough.
Using non-original replacement parts is not recommended.
Front Disc and Pads
1.
provide adequate working space underneath the frame. Support tractor
with safety stands. Be sure that positioning of safety stands does not
interfere with work task.
2. Remove front wheels.
3. Check friction pad wear.
NOTE: There are four pads in each caliper.
4. Pads should be replaced if any pad has 1/8 inch or less friction material
remaining.
5. Inspect brake disc for rust, scoring, ridges, and distortion. Light rust is
not harmful. Disc should be free of excessive or heavy scoring, but some
scoring is natural. If scoring is deeper than .080-in., replace both discs.
Any cracks require disc replacement.
6. Clean up minor roughness with an emery cloth. Discs can be repaired by
honing to a minimum thickness of 0.85”.
7. If brake disc has heavy scoring, ridges, or blue heat spots, machining the
disc may eliminate these problems.
8. Maximum friction surface lateral (side-to-side wobble) allowed is 0.030"
total.
9. Replace disc if wear or distortion exceeds these values.
Wheel Cylinders and Brake Shoe/Drum Assemblies
1. Pull the rear wheel and drum assemblies. Refer to 2-4 - 4.2.
2. Use a dry bristle brush or a clean lint-free cloth to remove lining dust from
shoes, backing plate, springs, drum, and wheel cylinder.
