7.3.3 Lubricant quantities
Pos: 22 5 /Anleitungen/Getriebe/7. Anhang/Schmierölmengen_02 [B1050] @ 32\mod_1553674626740_388.docx @ 2521700 @ @ 1
NOTICE! Gear unit damage
Failure to comply with this will result in damage to the gear unit.
• When filling, always use the oil level screw as an indicator of the precise quantity of oil. After filling, the oil
level must be checked as described in Section 5.2.6 "Oil level".
Pos: 22 6 /Anlei tung en/G etrieb e/7. A nhang /Sch mierölm enge n_03 [B 1050 , B2050] @ 32\mod_1553087897580_388.docx @ 2516727 @ @ 1
Information
Lubricants
After changing the lubricant, and in particular after the initial filling, the oil level may change during the first few
hours of operation, as the oil galleries and hollow spaces only fill gradually during operation.
• We recommend that the oil level is checked and corrected as necessary after an operating time of 2 hours..
Pos: 22 7 /Anlei tung en/G etrieb e/7. A nhang /Sch mierölm enge n_04- Stirnrad [B1050, B2050] @ 32\mod_1553087913389_388.docx @ 2516767 @ 4 @ 1
7.3.3.1 Helical gear units
The filling quantities stated in the following tables are for guidance only. The precise values vary
depending on the precise speed ratio and must be obtained from the type plate.
1)
Lubricant circulation (Option LC)
2)
Lubricant circulation (Option LCX)
3)
Full oil level (Option OT)
[L] M1 M2 M3 M4 M5 M6 OT
SK 5207 / 5307 21 31 26 39 37 37 54
3)
SK 6207 / 6307 26 37 32 45 42 42 63
3)
SK 7207 / 7307 36 45 36 58 46 46 98
3)
SK 8207 / 8307 44 55 48 75 57 57 106
3)
SK 9207 / 9307 57 71 73 76 74 74 150
3)
SK 10207 / 10307 72 89 90 96 92 92 180
3)
SK 11207 /11307 105 130 50
2)
105 140 40
2)
135
1)
45
2)
135
1)
45
2)
193
3)
SK 12207 / 12307 116 185 83
2)
149 203 65
2)
199
1)
69
2)
199
1)
69
2)
268
3)
SK 13207 /13307 154 256 107
2)
201 290 73
2)
268
1)
95
2)
268
1)
95
2)
353
3)
SK 14207 /14307 225 374 156
2)
291 424 107
2)
392
1)
139
2)
392
1)
139
2)
531
3)
SK 15207 /15307 358 415 160
2)
314 450 125
2)
405
1)
170
2)
412
1)
163
2)
550
3)
Table 17: Lubricant quantities for helical gear units
