Nord Drivesystems B 1050 Series User Manual

Industrial gear units – Operating and Assembly Instructions
76 B 1050 en-1819
Pos: 17 9 /Anlei tung en/G etrieb e/5. In spekti on un d Wartu ng/Be- und Entlüftung_06-Troc ke nmi ttel filt er [B1 050] @ 31\mod_1553011540242_388.docx @ 2514562 @ 4 @ 1
5.2.7.3 Drying agent filter (Option: DB)
NOTICE!
Gear unit damage
The separate filter manufacturer’s documentation must be observed.
The drying agent filter uses silica gel as the filter material. The condition of the filter is visible from the
outside. With increasing contamination the colour of the filter material changes from blue to pink. The
colour change starts in the lower area and spreads to the upper area The filter should be replaced
when three quarters of the filter have changed colour.
1. Check the degree of contamination.
2. Optional: Unscrew the old ventilation filter.
3. Optional: Screw in the new ventilation filter with a new sealing ring (7.4 "Torque values").
Pos: 18 0 /Anlei tung en/G etrieb e/5. Inspektion und Wartung/Gummipuffer [B1050_B2050] @ 17\mod_1493122189113_388.docx @ 2343229 @ 3 @ 1
5.2.8 Rubber buffer (Option: ED)
Gear units with an elastic torque support (Option ED) have rubber elements. If these show damage
such as tears to the rubber surface, the elements must be replaced. In this case, please contact
NORD Service.
Pos: 18 1 /Anlei tung en/G etrieb e/5. In spekti on un d Wartu ng/ Leit ung en_ 01 [ B1 050, B20 50] @ 31\mod_1553070251385_388.docx @ 2514650 @ 3 @ 1
5.2.9 Piping
Pos: 18 2 /Anlei tung en/G etrieb e/5. In spekti on un d Wartu ng/Leit ung en_02- Verrohrung [B1050, B2050] @ 31\mod_1553070281034_388.docx @ 2514728 @ 4 @ 1
5.2.9.1 Piping (Option: LC, LCX, OT)
The piping of lubrication circulation systems or vent lines for full oil level in combination with oil level
tanks must be checked for leaks.
The affected pipes must be replaced in case of leaks. In this case, please contact NORD Service.
Pos: 18 3 /Anlei tung en/G etrieb e/5. In spekti on un d Wartu ng/Leit ung en_03- Schl auchl eitung en_0 1 [B105 0, B20 50] @ 31\mod_1553070311792_388.docx @ 2514767 @ 4 @ 1
5.2.9.2 Hose lines (Option: LC, LCX, CS1, CS2, OT)
Pos: 18 4 /Anlei tung en/G etrieb e/5. In spekti on un d Wartu ng/Leit ung en_05- Schl auchl eitung en_0 3 [B105 0, B20 50] @ 31\mod_1553070319660_388.docx @ 2514806 @ @ 1
Hose lines are used as intake and pressure lines for lubricant circulation and for cooling units. In
addition, if an oil tank is present, this is connected to the gear unit with hose lines.
Hose lines are subjected to a natural ageing process due to external influences (e.g. UV radiation) to a
greater extent than pipes.
When checking hose lines, look out for leaks, cuts, cracks, porous areas and chafing. In such cases,
the affected hose lines must be replaced. Please contact the NORD Service department.
