3 Assembly instructions, storage, preparation, installation
B 1050 en-1819 31
Pos: 58 /A nl eitu nge n/G etr iebe /3. Mont ag e, L ager ung , V orb erei tung , Aufs tell ung /Mot or _01 [ B10 50, B2 050 ] @ 2 7\mod_1551185696440_388.docx @ 2491387 @ 25 @ 1
3.9 Motor (Option: IEC, NEMA)
Pos: 59 /Anlei tung en/ Ge trie be/3. Mo nt age , Lag er ung, Vor ber eitu ng, Au fst ellu ng/M otor _0 3 [B 105 0, B20 50] @ 30\ mod_1552920336148_388.docx @ 2510953 @ @ 1
Risk of injury
Severe injuries may be caused by rapidly rotating parts when installing and servicing couplings.
• Secure the drive against accidental start-up.
• The operating and assembly instructions for the coupling must be observed.
The maximum permitted motor weights and the dimension "X max" stated in the table below must not
be exceeded when attaching the motor to an IEC or NEMA adapter:
Maximum permitted IEC and NEMA motor weights
IEC
132 160 180 200 225 250 280 315
NEMA
210T 250T 280T 324T 326T 365T
gravity
X max1) [mm]
200 259 300 330 370 408 465 615
Weight [kg]
100 200 250 350 500 700 1000 1500
1)
see Figure 8 for maximum permitted X dimension
Table 5: IEC and NEMA motor weights
