3.1 Transporting the gear unit
WARNING
Hazard due to heavy loads
Severe injuries and material damage due to falling, swinging or tipping heavy loads are possible.
• To prevent injury, the danger area must be generously cordoned off.
• Standing under the gear unit during transport is extremely dangerous.
• Use adequately dimensioned and suitable means of transportation. Lifting tackle must be designed for the
weight of the gear unit. The weight of the gear unit can be obtained from the dispatch documents.
• If geared motors have an additional eyebolt attached to the motor, this must not be used.
• Only the four ring bolts provided may be used for transporting the gear unit.
Slipping hazard
Transport damage to the gear unit or gear unit components may result from the leakage of lubricants. There is a
slipping hazard due to leaked lubricants.
• The drive unit must be inspected and may only be installed if no transportation damage or leaks are visible. In
particular the radial seals and the sealing caps must be inspected for damage.
NOTICE
Gear unit damage
Damage to the gear unit due to improper use is possible.
• Prevent damage to the gear unit. Impacts to the free ends of the shafts may cause internal damage to the
gear unit.
• The ends of the shafts must not be used for transportation, as this may seriously damage the gear unit.
An additional lashing point may be required for versions which deviate greatly from the following
illustrations, or in the case of additional drive units and components.
In this case, please contact NORD Service.
