Nord Drivesystems B 1050 Series User Manual

Industrial gear units – Operating and Assembly Instructions
58 B 1050 en-1819
Pos: 12 5 /Anlei tung en/G etrieb e/4. Inbetriebnahme/Interne Kühlanlage_01_(Inbetriebnahme) [B1050, B2050] @ 28\mod_1551349755431_388.docx @ 2492796 @ 2 @ 1
4.5 Internal cooling system (Option: CC)
Pos: 12 6 /Anlei tung en/G etrieb e/4. In betri ebna hme/I ntern e Kühla nlage_02_(Inbetriebnahme) [B1050] @ 31\mod_1552992188351_388.docx @ 2513499 @ @ 1
NOTICE!
Gear unit damage
The gear unit may be damaged by overheating.
• The drive may only be commissioned after the cooling spiral has been connected to the cooling circuit, and
the cooling circuit has been put into operation.
Pos: 12 7 /Anlei tung en/G etrieb e/4. In betri ebna hme/I ntern e Kühla nlage_ 03_(I nbetri ebn ahme) [B1050 , B2050] @ 31\mod_1552992003255_388.docx @ 2513423 @ @ 1
The coolant must have a similar thermal capacity as water (specific thermal capacity at 20 °C
c=4.18 kJ/kgK). Industrial water without any air bubbles or sediments is recommended as a coolant.
The hardness of the water must be between 1 dH and 15 dH; the pH value must be between pH 7.4
and pH 9.5. No aggressive liquids may be added to the coolant!
The coolant pressure must not exceed 8 bar . The necessary quantity of coolant is 10 l / min. The
maximum permissible coolant temperature is defined during the planning phase and can be found in
the order data.
We also recommend fitting a pressure reducer at the coolant inlet to avoid damage due to excessive
pressure.
Pos: 128 /A nleit ung en/G etr ieb e/4. In betr ie bna hme/ Int ern e Kü hla nlag e_0 4_(I nbet ri ebn ahm e) [ B10 50] @ 31\ mod_1552992011876_388.docx @ 2513461 @ 8 @ 1
If there is a danger of frost the operator should add a suitable anti-freeze solution to the cooling water.
The temperature of the cooling fluid and the cooling fluid flow rate must be monitored and ensured by
the operator.
Information
Thermostat
With a thermostat in the cooling water inlet, the volume of cooling water can be adjusted to the actual
requirements.
