Nord Drivesystems B 1050 Series User Manual

Industrial gear units – Operating and Assembly Instructions
78 B 1050 en-1819
Pos: 191 /A nleit ung en/G etr ieb e/5. In spe kti on u nd Wart ung /Tac oni te Di c htung _( Wart ung) [B 10 50] @ 17\ mod_1493123585562_388.docx @ 23433 85 @ 3 @ 1
5.2.12 Taconite seal
Input and/or output shafts may be equipped with Taconite seals, depending on the version. The
associated grease nipple is located either directly on the bearing cover or re-lubrication must be
carried out via a lubrication line.
Explanation
1
Bearing cover 1
2
Grease-filled gap
3
Conical grease nipple
4
Bearing cover 2
Figure 31: Re-greasing Taconite seals
The precise position of the grease nipple can be obtained from the specific dimension sheet for the
order. The seal must be filled with grease until clean grease emerges from the grease gap. Remove
excess grease.
Recommended grease: Petamo GHY 133N - Klüber Lubrication (7.3.1 "Roller bearing greases")
Information
Re-greasing
Optimal re-lubrication is achieved by rotating the gear unit shaft in 45 ° steps when lubricating and pressing in
grease until clean grease emerges from the shaft.
