Industrial gear units – Operating and Assembly Instructions
40 B 1050 en-1819
Pos: 72 /A nl eitu nge n/G etr iebe /3. Mont ag e, L ager ung , Vorbereitung, Aufstellung/Motorstuhl [B1050] @ 28\mod_1551191584952_388.docx @ 2491556 @ 2 @ 1
3.13 Motor mount (Option: MT)
Risk of injury
Risk of injury due to rapidly rotating components while the cover is removed:
• Secure the drive against accidental start-up
NOTICE! Gear unit damage
Gear units with motor mounts and belt drives are pre-adjusted prior to delivery:
• Check the alignment of the motor and the belt tension prior to commissioning the gear unit.
Pos: 73 /Anleitungen/Getriebe/3. Montage, Lagerung, Vorbereitung, Aufstellung/Riemenantrieb_01 [B1050] @ 27\mod_1550676071686_388.docx @ 2489266 @ 2 @ 1
3.14 Belt drives
DANGER Injury to persons
Risk of injury due to rotating parts and crushing.
• Before starting maintenance and adjustment work it must be ensured that all components of the machine are
in a safe position and that this cannot be changed during the maintenance and adjustment work.
• The belt pulley may be destroyed by excessive rotation speeds.
NOTICE!
Belt damage
Use of belts
• Before installation the axle spacing must be reduced so that the belt can be inserted into the groves without
the use of force. Forcible mounting by means of tyre levers, screwdrivers etc. is completely impermissible, as
this often causes invisible damage to the high quality, stretch-resistant tension cord or the surrounding fabric.
In the standard version, V-belt drives cannot be combined with a mounting flange or fan, as these options would
conflict with each other.
