EV Series Automated Dispensing Systems
12
Specifications
Item/Model E2V E3V E4V E5V E6V
Number of axes 3 3 3 3 3
Maximum working area
(X / Y / Z)
150 / 200 / 50 mm
(6 / 8 / 2")
250 / 300 / 100 mm
(10 / 12 / 4")
350 / 400 / 100 mm
(14 / 16 / 4")
450 / 500 / 150 mm
(18 / 20 / 6")
570 / 500 / 150 mm
(22 / 20 / 6")
Workpiece payload 5 kg (11.0 lb) 10 kg (22.0 lb) 10 kg (22.0 lb) 10 kg (22.0 lb) 10 kg (22.0 lb)
Tool payload 1.5 kg (3.3 lb) 3 kg (6.6 lb) 3 kg (6.6 lb) 3 kg (6.6 lb) 3 kg (6.6 lb)
Unit weight 29 kg (64 lb) 47.5 kg (105 lb) 52.5 kg (116 lb) 55 kg (121 lb) 58 kg (128 lb)
Dimensions
480
Wx435Hx510D mm
(19W x 17H x 20"D)
595Wx538Hx645D mm
(23W x 21H x 25"D)
695Wx638Hx645D mm
(27W x 25H x 25"D)
795Wx717Hx815D mm
(31W x 28H x 32"D)
915Wx717Hx815D mm
(36W x 28H x 32"D)
Maximum speed
(XY / Z)
500 / 250 mm/sec
(20 / 10"/sec)
800 / 320 mm/sec
(31 / 13"/sec)
800 / 320 mm/sec
(31 / 13"/sec)
800 / 320 mm/sec
(31 / 13"/sec)
800 / 320 mm/sec
(31 / 13”/sec)
Drive system
3-phase micro-
stepping motor
3-phase micro-
stepping motor
3-phase micro-
stepping motor
3-phase micro-
stepping motor
3-phase micro-
stepping motor
Memory capacity PC storage PC storage PC storage PC storage PC storage
Data storage PC storage / USB PC storage / USB PC storage / USB PC storage / USB PC storage / USB
General purpose I/O
8 inputs / 8 outputs
(16 / 16 optional)
8 inputs / 8 outputs
(16 / 16 optional)
8 inputs / 8 outputs
(16 / 16 optional)
8 inputs / 8 outputs
(16 / 16 optional)
8 inputs / 8 outputs
(16 / 16 optional)
Drive method PTP and CP PTP and CP PTP and CP PTP and CP PTP and CP
Dispensing controller External External External External External
Power supply
Auto-switching,
AC100–240V, 230 W
Auto-switching,
AC100–240V, 350 W
Auto-switching,
AC100–240V, 350 W
Auto-switching,
AC100–240V, 350 W
Auto-switching,
AC100–240V, 350 W
Interpolation 3 axes (3D space) 3 axes (3D space) 3 axes (3D space) 3 axes (3D space) 3 axes (3D space)
Repeatability* ±0.008 mm/axis ±0.008 mm/axis ±0.008 mm/axis ±0.008 mm/axis ±0.008 mm/axis
Working temperature 10–40° C (50–104° F) 10–40° C (50–104° F) 10–40° C (50–104° F) 10–40° C (50–104° F) 10–40° C (50–104° F)
Precision vision Included Included Included Included Included
DispenseMotion
software
Included Included Included Included Included
Tip detection system Optional Optional Optional Optional Optional
Approvals CE, RoHS, WEEE, China RoHS
*Repeatability results may vary depending on the method of measurement.
