EV Series Automated Dispensing Systems
70
Appendix A, Command Function Reference
(continued)
Circle
Click Function
Registers a circle with the circle’s center at the current XYZ location
Parameter Description
Diameter The diameter of the circle (in mm)
Start Angle The angle (in degrees) from the center of the circle where the start of the circle begins. The
default of 0 degrees equates to the 3:00 position.
Default: 0 (degrees)
Range: 0 to 360
NOTE: You can enter a negative value. For example, if you enter -90, the circle start point will
be the 12:00 position.
End Angle The angle (in degrees) after the Start Angle value at which dispensing stops.
Default: 0 (degrees)
To dispense in a counterclockwise direction, enter a negative value.
Dispense Dot
Click Function
Registers the current XYZ location as a Dispense Dot point.
Dispense Dot Setup
Click Function
Sets how the system dispenses a dot of uid.
Parameter Description
Valve On Time How long the dispenser stays open (in seconds).
Dwell Time Delay time (in seconds) that occurs at the end of dispensing to allow the pressure to equalize
before the tip moves to the next point.
